Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
Specifications
Brand Name :
WeSeW
Certification :
CE,UL
Place of Origin :
China
MOQ :
1pcs
Price :
US$200~US$1000/pc
Payment Terms :
T/T,Western Union
Supply Ability :
10,000 pieces per month
Delivery Time :
5-40days
Packaging Details :
Wooden Case
Product name :
Adjustable Speed Gear Reducer Motor
Nominal Voltage :
220V/380V
Application :
Farms, Retail, Building Material Shops, Manufacturing Plant, Machinery Repair Shops
Description

Customized Three-Phase 115/120V Horizontal Variable Frequency Speed Control Screw Four-Stage Gear Reducer 400W AC Motor IE2 Energy Efficiency Class Hardened Gear Surface Supplier


This three-phase AC motor features a helical gear reducer with a 10:1 reduction ratio and operates at 1400/1650 rpm input speed. It is suitable for various applications including packaging, printing machinery, and the chemical industry.


AC Voltage
115/120 V
Phase
Three-Phase
Rated Power
0.4kw
Rated Speed
7-450rpm
Model Number
CV/CH22-400-3-90S
Motor Mounting Type
Vertical/horizontal
Efficiency
IE 2
Frame
Cast iron
Frequency
50/60hz
Protect Feature
Totally Enclosed
Type
Gear Motor
Category
Gear reducer
Layout type
Coaxial
Application range
Packaging machinery, printing machinery, chemical industry, etc.
Customisation available
Yes
Gear type
Helical gear reducer
Tooth surface hardness
Hard tooth surface
Number of stages
Four stages
Input Speed
1400/1650 (rpm)
Allowed Torque
2.6 to 25.4 (N.m)
Reduction Ratio
10


This three-phase 115/120V horizontal variable speed spiral four-stage gear reducer AC motor is specifically designed for industrial equipment, delivering stable and efficient power transmission. Featuring a helical four-stage gear reduction structure, it achieves precise torque amplification and speed control, suitable for applications such as conveyor belts and mixers. The variable frequency speed control function supports stepless speed adjustment, significantly improving energy efficiency and extending equipment lifespan. With 400W power output, it is compatible with small to medium-sized machinery, ensuring smooth and reliable operation with easy installation.



Coaxial Layout: Efficient use of space and compact design for easy installation.

Helical Gear Reducer: Smooth and quiet operation with high torque output.

10:1 Reduction Ratio: Significantly reduces input speed while maintaining efficiency.

IE2 Efficiency: Meets international energy-saving standards, saving on electricity costs.

Strict Quality Inspections: Ensures reliability and long lifespan of the motor.


Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive

Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive

Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive

Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive

Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive

Three-Phase 115/120V 400W Power Output IE2 Energy Efficiency Gear Reducer Motor with Variable Frequency Drive
