Specifications
Brand Name :
WeSeW
Model Number :
W003
Certification :
CE/UL
Place of Origin :
china
MOQ :
1 pc
Price :
US$75000~US$20,000/set
Payment Terms :
T/T,Western Union
Supply Ability :
10,000 pieces per month
Delivery Time :
20~35 working day
Packaging Details :
Wooden Case
Material :
Stainless steel
Material Feature :
Heat Resistant, Fire Resistant
Application :
Chemical Industry, Grain Transport, Mining Transport, Power Plant
Applicable Industries :
Manufacturing Plant, Energy & Mining
Core Components :
Motor, Engine
Dimension(L*W*H) :
Customized
Specification :
Customized
Structure :
Chain Conveyor
Description

tube chain conveyor system full enclosed tubular chain conveyor pipe chain conveyor

Tube Chain Conveyor, also called plate chain conveyor, is a mechanical system that operates in a seal pipe. Its feature is the stable property and saving the energy consumption in conveying system. It can contiguously convey bulky material, such as powder,fine particle and small lump and so on. It can convey in the level, the incline and the vertical. It widely applies in the chemical industry, the chemical fiber, the agricultural chemicals, ore, the food industry, the building materials, ect..

SPECIFICATIONS FOR BELT CONVEYOR
Motor
Motor Power
Kw
4-80
Power
Voltage
380/220
Main performance parameters
Chain Wheel Speed
r/min
8-20
Chain plate speed
m/s
3
Conveying Quantity
CBM/h
4-80

Steel wire rope conveyor
1.Compact structure, Can be universal turning
2.No dead area
3.discharge at multiple points; no special airlocks
4.adjustable plate spacing
5.Suitable for small capacity material conveying
6.Cheaper than the plate chains, chains
7.Low maintenance cost

Model
Capacity(m³/h)
Chain Wheel Speed(r/min)
Chain Plate Speed(m/s)
Motor powder(kw)
GL80
4
20
0.29
4
GL100
8
18
0.31
5.5
GL150
16
15
0.31
7.5
GL200
28
12
0.3
11
GL250
48
10
0.3
15
GL300
60
8
0.28
18.5
GL400
80
8
0.28
22

Technology advantage
1. Scientific Design--In chain conveyor design, we have anti-off chain device and chain-broken protection device, matching color disc, the chain reverse recognition; add emergency outlet to ensure resume production rapidly.
2. Perfect Service--Have rich experience on manufacturing and installing. There are enough spare parts.
3. Rich Experience--Boyang chain conveyors have rich experience based on being use in most industries and treat widest range materials. Max Capacity is 300m³/h.Vertical conveying length up to 40 m,and horizontal conveying length up to 60 m.
4. Powerful Strength--Boyang Machinery Company is strong in technology and established research base with universities. It has two research centers. It is high-new-tech enterprise with more than 30 engineers and technicians.
5. Advanced Technology--Advanced control system,with online status detection system,could timely alarm interlock in the case of abnormal running to avoid equipment accidents.
6. Excellent Performance--The sofe disc could bear high temperature up to 250℃.The system could working at 500℃.
