Excavator concrete hydraulic rock hammer breaker
Excavator concrete hydraulic rock hammer breaker
Specifications
Brand Name :
FENGHUANG
Model Number :
1.5-45Ton excavator
Certification :
ISO
Place of Origin :
GUANGZHOU
MOQ :
1
Payment Terms :
Western Union, MoneyGram, T/T
Delivery Time :
1~3
Packaging Details :
Different packaging methods are adopted according to different modes of transport.
Suitable Excavator(ton) :
6-9ton
Warranty :
1 Year
Weight :
430 kg
Core Components :
Main body
Machinery Test Report :
Provided
suitable for excavator :
0.8-120ton
Working Flow :
50-90L/Min
Hose diameter :
1/2inch
Suitable Excavator :
3-7on
Color :
Customerized
Place of Origin Shandong, China Warranty 1 Year Weight 430 kg Core Components Main body Video outgoi :
68mm/75mm/140mm/155mm
Impact rate :
400-800bpm
Applicable Industries :
construction/demolition machinery
Description

Excavator concrete hydraulic rock hammer breaker

Range for 1.5-45Ton excavator
Side type, top type, box silenced type, backhoe type, skid-steer type available.
High quality cylinder ensure the powerful impact force.

HYDRAULIC BREAKER SPECIFICATIONS

HMB Model

Operating Weight (kg)

Required Oil Flow (L/Min)

Working Pressure (Bar)

Impact Rate (Bpm)

Chisel Diameter (mm)

Hose Diameter (inch)

Carrier weight (ton)

Valve Ass'y Position (/)

PHX450

150

20-40

90-120

700-1200

45

1/2

1.2-3

Internal

PHX530

190

25-45

90-120

500-1100

53

1/2

2.5-3

Internal

PHX680

340

36-60

110-140

500-900

68

1/2

3-7

Internal

PHX750

480

50-90

120-170

400-800

75

1/2

6-9

Internal

PHX850

580

45-85

127-147

400-800

75

3/4

7-14

Internal

PHX1000

950

80-120

150-170

400-650

100

3/4

10-15

Internal

PHX1350

1650

130-170

160-185

400-650

135

1

18-25

Internal

PHX1400

2000

150-190

165-195

400-800

140

1

20-30

Internal

PHX1550

2900

150-230

170-200

400-800

155

1

27-36

Internal

PHX1650

3250

200-260

180-200

250-400

165

5/4

30-45

Internal

PHX1750

4150

210-280

180-200

250-350

175

5/4

40-50

Internal

PHX1800

4200

280-350

190-210

230-320

180

5/4

45-55

Internal

PHX1900

4230

280-350

190-210

230-320

190

5/4

50-60

Internal

Excavator concrete hydraulic rock hammer breaker

Main Features:
1. Cylinder&valves: prevents wear with precision finishing treatment.
2. Piston: improved running properties; manufactured with high-quality nickel&vanadium alloy steel.
3. Chisel: exceptinal performance and reliability; manufacutred with high-quality alloy steel.
4. Accummulator: reduces irregular pulse pressure on hydraulic circuit; improved striking power with supply of accumulated gas pressure.
5. Oil seal: increase hydraulic circuit design at the sied of under pressure, reduce the pressure of oil seal, improve service
life.
