Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power
Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power
Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power
Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power
Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power
Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power
Specifications
EVM :
8%
Bands Support :
VHF, UHF, N71, N28, N5, N20, N8, N66, N3, N1, N40, N7, N78, N77, N79
VSWR :
≤1.8
Noise Figure :
8dB
Brand Name :
ATNJ
Model Number :
DS-VHF
Certification :
CE,ROHS，CCC，TUV,BV， ISO
Place of Origin :
China
MOQ :
5Pcs
Price :
USD+800+PCS
Supply Ability :
1000+unit+per day.
Delivery Time :
45 work days
Packaging Details :
Standard neutral packing
Network Protocols :
TETRA/P25/DMR/GSM/WCDMA/LTE/NR/WiFi
Payment Terms :
T/T,Western Union,Paypal,Bank transfering
Output Power :
UL: 20±2 dBm, DL:33±2 dBm
Spurious Emission :
9KHz-1GHz: -36dBm , 1GHz-12.75GHz: 30dBm
Power Supply :
AC100/ 240V
Gain :
UL:80±2 dB,DL:85±2 dB
150MHz Frequency Range :
UL151-153MHz,DL161-163MHz
Description
VHF Digital Repeater System 150MHz Digital Band Selective Repeater System for Customized Use

Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power

Digital VHF BDA Band Selective Repeater System

A VHF BDA Digital Repeater is a telecommunications device used to extend the coverage range of Very High Frequency (VHF: 30-300 MHz) digital radio communication systems.

Core Functions
  • Signal Reception: Receives weak/attenuated digital radio signals (e.g., DMR, dPMR, P25 Phase 2) within the VHF band from user equipment (e.g., handheld radios)
  • Digital Processing: Decodes, regenerates, and error-corrects the digital signal (unlike analog repeaters that amplify noise)
  • Signal Retransmission: Rebroadcasts the cleaned digital signal at higher power to distant or obstructed areas
Key Advantages
  • Extended Coverage: Overcomes terrain obstructions (buildings, hills) and VHF range limitations (~5-50 km line-of-sight)
  • Signal Integrity: Regeneration prevents noise/error accumulation, maintaining voice/data quality
  • Spectral Efficiency: Supports digital modulation (e.g., TDMA), enabling multiple users on one frequency
Features
  • Digital filtering supports adjustable bandwidth, each band supports three sub-bands
  • Each sub-band is turned on and off, and gain control is performed separately
  • Donor signal monitoring for easy optimization and troubleshooting
  • Intelligent algorithm to prevent UL interference
  • Self-control to minimize interference for new rollout e-Node B
Technical Specifications
Items Specifications
System VHF
Frequency Range Uplink(Rx): 150-153MHz (At least 5MHz Guard Bandwidth Between Uplink and Downlink)
Downlink(Tx): 161-163MHz (At least 5MHz Guard Bandwidth Between Uplink and Downlink)
Bandwidth Customized
Maximum Output Power Uplink: 20±2dBm
Downlink: 33±2dBm
Maximum Gain 80±3dB
AGC Range ≥20dB
Maximum Input power (Non-Destructive) ≤-10dBm
VSWR ≤ 2.4
System Delay ≤ 6 μs
I/O Impedance 50 Ω
Noise Figure ≤ 8dB
Spurious Emission 9kHz-1GHz: ≤ -36dBm
1GHz-12.75GHz: ≤ -30dBm
Third-order Inter-Modulation ≤ -40dBm
RF Connector 2*N-Female
Power Consumption ≤ 30W
Power Supply Input: AC100-240V, 50/60Hz
Dimensions 450*335*180mm
Weight ≤ 12kg
Alarm Monitoring System Alarm for Uplink Self-Oscillation
Isolation Detection Isolation Check During Boot Time
Operating Temperature -10 to +50 °C
Application Indoor or Outdoor (IP65)
Relative Humidity Range ≤95% (Non condensing)
Mounting Wall Mounting
Product Images
Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power Public Safety VHF Digital Repeater System with 150MHz Frequency Range, 80dB Gain, and 33dBm Output Power
ATNJ Strength & Service
  • Extensive Product Portfolios: We offer a wide range of products, ensuring that you have access to a diverse selection that meets your specific requirements
  • High End Concept: Our relentless pursuit of the latest technology and our unwavering dedication to commercialization and massive production sets us apart
  • Strong R&D Team: We boast a team of talented and highly skilled professionals who consistently push the boundaries of innovation
  • Customized Product Development: With our exceptional ability to develop customized products in the industry, we ensure that the unique needs of our customers are met with the highest precision and efficiency
  • Expert Solutions: A team of experts with 20 to 30 years of experience is committed to providing perfect solutions, specifically tailored to the challenges faced by our valued customers
  • ISO/CE Certified Quality: Our commitment to excellence is underscored by the certification of our products, ensuring superior quality and reliability
Frequently Asked Questions
1. Are you trading company or manufacturer? Could I use our own logo and label?
We are the factory, with good trading service. We provide OEM/ODM service.
2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.
3. Is it easy to set up your items?
Yes. We have a user manual and support technical support 24/7.
4. What is your warranty time?
We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.
5. What is our Certificates?
We have CE, ROHS, CCC etc, certificates.
6. Please feel free to contact us if there are any other questions.
Contact our support team for additional assistance.
