33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
Specifications
2100MHz Frequency Range :
1920–1935/2110–2125MHz; 1935-1950/2125-2140MHz
RF Connector(Customers to Choose) :
N -Type (Female)
Payment Terms :
T/T,Western Union,Paypal,Bank transfering
Bandwidth :
Wide Range
Brand Name :
ATNJ
Model Number :
DS-33-GDW-4
Certification :
CE,ROHS，CCC，TUV,BV， ISO
Place of Origin :
China
MOQ :
5Pcs
Price :
USD+820---900+pcs
Supply Ability :
1000+unit+per day.
Delivery Time :
5-15 work days
Packaging Details :
Standard neutral packing
900MHz Frequency Range :
890–910MHz/ 935–955MHz
Bands Support :
VHF, UHF, N71, N28, N5, N20, N8, N66, N3, N1, N40, N7, N78, N77, N79
Network Protocols :
TETRA/P25/DMR/GSM/WCDMA/LTE/NR/WiFi
Local Control :
WIFI/ Type-C Port, Bandwidth Adjustment Could Be Done By Type-C Only
Remote Control :
Cloud WEB Platform By SIM Card
1800MHz Frequency Range :
1745–1765MHz/1840–1860MHz
Description
33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
Product Overview

33dBm Outdoor Selective band Signal Booster LTE 900/1800/2100MHz 4G Wideband Signal Amplifier for Rural Area

Product Introduction

The digital Repeater is designed to provide a more cost-effective solution than adding a new Base Transceiver Station (BTS) to improve signal coverage and communication quality in single system. Its easy installation and maintenance helps carriers achieve fast return on investment.

The device functions as a relay between the BTS and mobile devices. It receives low-power signals from BTS via the Donor Antenna, linearly amplifies the signal, and retransmits it via the Coverage Antenna to weak or blind coverage areas. Mobile signals are also amplified and retransmitted to the BTS in the opposite direction.

Key Features
  • Intelligent installation guidance with LCD display
  • Real-time signal strength display
  • Automatic dormancy when no calls are active
  • Automatic alarm for installation errors with solutions
  • Automatic system gain adjustment to prevent self-excitation
  • Proactive damage detection and alerts
  • Supports bandwidth adjustment from 0.2 to 20MHz (customizable)
  • Supports 5G bandwidth: 40MHz, 50MHz, 60MHz, 70MHz, 80MHz, 90MHz, 100MHz (customizable)
  • WiFi Monitor + Control (customizable), NMS (network management system) - optional functions
Technical Specifications
SPECIFICATIONS PARAMETERS
Frequency Range 900MHz | UL890-910MHz, DL935-955MHz
1800MHz | UL1745-1765MHz, DL1840-1860MHz
2100MHz | UL1920-1935MHz, DL2110-2125MHz
2100MHz | UL1935-1950MHz, DL2125-2140MHz
Bandwidth 900MHz | supports 1 subband from 0.2 to 20 MHz adjusted
1800MHz | supports 1 subband from 0.2 to 20 MHz adjusted
2100MHz | supports 2 subband from 0.2 to 15 MHz adjusted
RF Carriers ARFCN Filtering Digital
Gain UL: 75±3 dB DL: 80±3dB
Output Power UL: 20±2dBm DL: 33±2dBm
Automatic Gain Control 30dB/1dB
Minimum Input power ≥ -90dBm
Gain Flatness / PB Ripple ＜ 4dB
Automatic Level Control ≥ 25dB
Unwanted emissions Fully comply with 3GPP 36.106
EVM ≤8
VSWR ≤1.8
Noise Figure ≤8dB
Delay ≤10μs
RF Connector N-Type (Female) - Customers to Choose
Storage temperature range -40°C to +85°C
Operating Temperature -25°C to +55°C
Power Supply 195-265 VAC
Power consumption ≤100W
Barometric pressure 55 kPa -106 kPa
Environment Conditions IP65
Relative humidity 5% - 95%
Weight ≤20kg
Size 596 x 400 x 203.5 mm
Product Images
33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz 33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
Frequently Asked Questions
Why choose us for cooperation?
We have professional engineers to develop products suitable for worldwide use. We provide comprehensive support and respond to any problems you may encounter at any time.
Does the signal booster work have radiation or not?
Yes, but only minimal amounts. The booster can actually reduce radiation exposure during calls, as poor signal conditions typically result in higher radiation emissions from mobile phones. The device is safe for indoor use and provides better protection than using a phone directly in low-signal areas.
Can I install a signal repeater myself?
Absolutely. No technical expertise is required to install your mobile signal repeater kit. Each kit contains everything needed to improve mobile coverage in your home or office, with clear instructions guiding you through the simple installation steps.
Can this mobile signal repeater create a signal where there is no cell signal before?
The mobile signal repeater cannot produce a signal; it can only amplify an existing weak signal to improve coverage and quality.
