3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
Specifications
Impedance :
50OHm
Shield :
Al Foil+braiding
Length :
50M,100M,300M
Insulation :
Foam PE
Weight :
1.3Kg--8.2Kg
Cable :
3D-FB RG58
Brand Name :
ATNJ
Model Number :
3D-FB
Certification :
CE,ROHS，CCC，TUV,BV， ISO
Place of Origin :
China
MOQ :
5Pcs
Price :
USD+18--115+kit
Supply Ability :
1000+unit+per day.
Delivery Time :
3-5 work days
Packaging Details :
Standard neutral packing10*10*5cm(1pcs),
Products type :
signal amplifier 4g
Payment Terms :
T/T,Western Union,Paypal,Bank transfering
Color :
White
Description


3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M



Product Description

Electrical Properties and Mechanical Properties :
1. Characteristic impedance : 50 ohm
2. Rated capacitance : 82 pf/m
3. Velocity of propagation : 84 %
4. Operating frequency : 1- 6000 MHz
5. Operating temperature : - 25°C ~ +70°C
6. Minimum bending radius : 61 mm
7. VSWR : 1~3000 MHz≤1.15 ; 1~6000 MHz≤1.20

Cable Construction :
1. Inner conductor : Bare Copper or Copper Clad Aluminum, 1.42mm Diameter
2. Insulation Layer : Foam Polyethylene (FPE), 3.81mm Diameter
3. Outer Conductor : Single-sided Self-adhesive Aluminum Tape Tinned Copper, 4.52mm Diameter
4. Jacket : Polyvinyl Chloride(PVC ) or Polyethylene (PE), 6.10mm Diameter


RG58 Basic construction

RG58

CONDUCTOR
MATERIAL
BC/CCS
Nom.Dia.
7*0.16mm(0.48mm)

DIELECTRIC
MATERIAL
PE
Nom.Dia.
1.60mm

SHIELD
MATERIAL
TC Braiding
COVERAGE
90%

JACKET
MATERIAL
PVC
Nom.Thick.
0.5mm
Nom.Dia.
2.7±0.10mm

Further detail pls click here for downloading the products specification:

ATNJ Mobile Signal Repeater.pdf


3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M

3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
3D FB RG58 Signal Booster Coaxial Cable Customized Length 50M 100M 300M
No matter where you are, we always have a way to deliver it to customers !


FAQ :
Q1 : Are you trading company or manufacturer ? Could I use our own logo and label?

A1 : We are factory, with trading service. We provide OEM/OEM service.

Q2 : Can I have a sample order? What is your MOQ?
A2 : Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

Q3 : Can I get samples to test before I place an order?
A3 : Yes ,samples are available,and the samples are refundable after you place an order.


Q4 : How do you factory think about quality control?
A4 : Quality is the most important,and that's why the raw material we choose are of high quality.


Q5 : Do you accept OEM order and how long will you shipping after place an order?
A5 : We can manufacture according to customer's request and usually we can deliver goods 15-20 days after we receive your deposit.

Q6 : What is your payment terms?
A6 : We accept Trade Assurance, T/T, West Union, Paypal, Bank Account Transfering.
