CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
Specifications
Brand Name :
CUSTOM
Model Number :
VKP80III
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10,000 Pieces Per Year
Delivery Time :
It depends on the quantity of your order
Packaging Details :
Carton / Pallet
Type :
Kiosk Printer VKP80III RX63 USB RS232 REAR CN
Model :
915DX010700300
Application :
ATM, self-service equipment, kiosks, banking terminals
Interfaces :
USB + RS232
Warranty :
90 Days
Emulation :
CUSTOM/POS
Description
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
The 915DX010700300 CUSTOM VKP80III is a top-selling, reference-grade kiosk printer trusted in over 70 countries worldwide. Designed for receipts and tickets in ATMs, self-service kiosks, and banking terminals, it combines compactness, flexibility, and ruggedness with a high-performance processor and long-lasting print head. Its adjustable roll holder and 6 mounting positions make it ideal for any kiosk design, while advanced features like a patented anti-jam system and illuminated paper bezel ensure reliable, user-friendly operation.
Key Features & Highlights
  • Dual Interface Support: Equipped with standard USB and RS232 interfaces, compatible with most ATM and self-service terminal systems, easy to connect and configure.
  • High Performance: Thermal printing technology ensures fast output speed, clear print quality, and low noise, suitable for 24/7 unattended operation.
  • Durable & Reliable: Robust structure, anti-jam paper feeding design, and high-quality print head ensure long service life, reducing maintenance frequency.
  • OEM Custom Spare Parts: We provide customized spare parts (including print heads, paper feed rollers, cutters, interfaces, etc.) according to your specifications, supporting OEM/ODM requirements.
  • Easy Installation & Maintenance: Compact size, lightweight design, and standardized installation interface, making it easy to embed and maintain.
Technical Specifications
Model Number 915DX010700300
Name CUSTOM VKP80III RX63 USB RS232 REAR CN
Print Speed > 250 mm/sec
Print Head Life 200 km / 100 Ml pulses
Paper Width 50 - 82.5 mm
Paper Weight 55 - 110 g/m²
Roll Dimension Max 150 mm (up to 250 mm with optional roll holder)
Cutter Life (MCBF) > 1,000,000 cuts
Interfaces RS232 + USB; ETH + USB (optional)
Data Buffer 16 KB text / 1 MB graphics
Flash Memory 5 MB (1 MB user-available)
Drivers Windows (32/64 bit), Linux (32/64 bit), Virtual COM, OPOS, Android, iOS
Power Supply 24 Vdc ±10%
Medium Consumption 1A (12.5% dots turned on)
MTBF (Electronic Board) 450,000 hours
Operating Temperature -20°C to +70°C
Dimensions (L×H×W) 143.5 × 76.4 × 116 mm
Weight 0.8 kg
Character Set PC437, PC850, PC860, PC863, PC865, PC858
Printing Format Normal, height/width 1x-8x, reverse, underlined, italic, bold
Printing Direction Straight, 90°, 180°, 270°
Emulation CUSTOM/POS
Sensors Paper end, ticket presence, paper output, open cover, near paper end, print head temperature; VeriNotch (mobile notch/black mark sensor); optional TopNotch
Applications
  • ATMs & Banking Terminals: Printing withdrawal slips, transaction receipts, and account statements.
  • Self-Service Kiosks: Ticketing, parking payment, queue management, and retail check-in systems.
  • Outdoor & Industrial Kiosks: Withstands -20°C to +70°C temperatures, ideal for semi-outdoor deployments.
  • Gaming & Vending: Reliable ticket and receipt printing in high-volume environments.
Accessories for VKP80III
963GE020000071 POWER SUPPLY 24V 60W CONNECTOR DIN
974DX010000001 VKP80III PAPER ROLL HOLDER + NPE KIT
976DX010000008 KIT SHUTTER VKP80III VKP80III
976DX010000004 KIT CABLE NPE L230MM+BOARD NPE KIT80III
976DX010000002 STARTER KIT VKP80III
41000000054400 BLACK PAPER MOUTH WITH LED
976DX010000013 BLUE PAPER MOUTH WITH LED
26900000000005 CABLE ADAPTER POWER SUPPLY
26500000000352 CABLE RS232 9M / 9F 1.8M
26500000000356 USB CABLE A MASC B MASC 1.8MT
26300000000579 POWER SUPPLY CABLE 1MT
26100000000311 SCHUKO POWER CORD
26100000000313 UK POWER CORD
26900000000335 CABLE RS232/DB9F VKP80III
Our professional R&D and manufacturing team will work with you to confirm specifications, provide samples, and ensure the custom parts perfectly match your equipment, helping you achieve product differentiation and cost optimization.
CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300 CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300 CUSTOM Kiosk Printer VKP80III RX63 USB RS232 REAR CN 915DX010700300
Contact Us
Ready to upgrade your kiosk with the 915DX010700300 CUSTOM VKP80III? Contact our sales team for a quote, custom solutions, or more information:
Email: sales@atmpart.com.cn
WhatsApp: +86 13926975636
