Large Capacity Bitumen Heating Tank Asphalt Storage Tank Intelligent Control
Large Capacity Bitumen Heating Tank Asphalt Storage Tank Intelligent Control
Specifications
Brand Name :
WUHANCS
Certification :
ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiatable
Payment Terms :
T/T
Delivery Time :
40 working days
Size :
12192mmx2438mmx2591mm
Capacity :
40000L-45000L
Material :
Carbon Steel
Heating System :
Burner direct heating system
Transport :
Container vessel
Suitable for :
Asphalt Storage, asphalt emulsion plant, asohalt modification plant
Customized service :
Available
Description

Large Capacity Bitumen Heating Tank Asphalt Storage Tank Intelligent Control

Item Description QTY & Specification Remarks
1 Shape Tank Container Type
2 Outline dimension(mm) 12192x2438x2591 40ft

3

 Gross capacity(m3) 45
Effective capacity(m3) 40 95% filled
4 Tare weight(kg) 11000
5 Insulation layer(mm) 50 Rockwool
6 Insulation layer outsourcing(mm) 0.6 Color steel plate
7 Temperature drop rate (℃/h) ＜2
8 Thickness of the ends(mm) 6-8
9 Direct visual temperature meter 1
10 Temperature sensor 1
11 Maintenance manhole 1 Ø500 mm
12 Breather valve 2
13 Pressure(MPa) ＜0.1 Normal pressure
14 Operating temperature -19℃~200℃
15 Ladder 1 W=400mm
16 Heating system One set, hot pipe direct heating, twin burner tubes 2 Groups
17 Diesel oil burner 2, 200000Kcal/unit Italy
18 Automatic control system 1 230/460V, 60Hz
19 Pressure transmitter 1 E﹢H
20 Vertical agitator 4.5KW With SIMENS electric motor,
21 Liquid level switch 1
22 Drain hole 1 DN100
23 Asphalt inlet pipe 2 DN50/ DN125
24 Asphalt outlet pipe 2 DN 125 mm
25 Overflowing hole 1 DN 108mm
