6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
Specifications
Brand Name :
ASLONG
Model Number :
JGY-N20
Certification :
CE
Place of Origin :
CHINA
MOQ :
10 Pieces
Price :
Negotiation
Packaging Details :
on-the-spot foaming package 13*10*8 20*15*10 42*32*16 42*32*32
Protect feature :
Totally Enclosed
Gear arrangement :
worm gearbox reductor
motor character :
high speed dc motor
reduction :
gear structor
Description

6v 12v DC Worm Gear Motors 381rpm N20 Speed Reduction Motor

Micro Worm Gearbox Reducer with n20 dc motor samll worm geared reduction motor

1.Standard Operating Conditions:1-1 Rated Voltage:6v 12v 24v;
1-2 Direction of Rotation:CW when viewed from output shaft side
1-3 Operating Temperature and Humidity:Temperature range of -10C~+50C,Humidity range of 30%~80%.
1-4 Storage Temperature:Temperature range of -20C~+60C
2.Measuring Conditions:
2-1Motor Position:To be place t horizontally when measuring;
2-2Power Supply: Regulated
DC power supply
--No load speed:8-381rpm.
--Robotics, Small Appliance, Fanner, Electric Curtain; --Medical Pump, Surgery Tools, Medical Stirrer, centrifugal Machine;
Electric Valve, Actuator, medical device
--Electric motor,low noise,low current and no spark.
Ratio: 42:1 118:1 236:1 302:1 603:1 1016:1

N20 electric dc motor : 12v 16000rpm 06v 8000rpm
Remark:Pls confirm the voltage and speed before ordering,
if you don't reply within 8 hours after ordering,we will random send one for this type,hope your kindly understanding.
6v 12v DC Worm Gear Motors 381rpm n20 speed reduction motor
N20 worm gear motor data sheet :
JGY-N20 Parameter
Model Gear
Ratio
00:1		 No-loading Rated loading Stall
Rated
volt		 Speed Current Speed Current torque Power
dc motor		 Torque Current
v Rpm mA Rpm mA KG.CM w KG.CM mA
12160 42 12 381 30 333 85 0.071 1 0.235 700
118 12 136 30 119 85 0.142 1 0.472 700
236 12 68 30 59 85 0.283 1 0.9441 700
302 12 53 30 46 85 0.362 1 1.208 700
603 12 27 30 23 85 0.579 1 1.9296 700
680 42 6 190 20 143 60 0.022 1 0.0735 350
118 6 68 20 51 60 0.062 1 0.206 350
236 6 34 20 25 60 0.124 1 0.413 350
302 6 26 20 20 60 0.159 1 0.528 350
603 6 13 20 10 60 0.317 1 1.055 350

Ask for a quotation for mass production quantity, contact us or customizations and integration.


FAQ
1. who are we?
We are based in Guangdong, China, start from 2005,sell to North America(30.00%),Domestic Market(15.00%),Western Europe(10.00%),Eastern Europe(10.00%),Northern Europe(6.00%),Southern Europe(5.00%),Southeast Asia(5.00%),South America(5.00%),Oceania(5.00%),South Asia(4.00%),Africa(3.00%),Eastern Asia(2.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Gear Motor,DC Motor,Brushless Motor,Planetary Gear Motor,Worm Gear Motor

4. why should you buy from us not from other suppliers?
Specialized in Micro DC motor, Dc Gearbox motor.We have been in this industry for over 10 years,we have many experinec to provide motors according to customer's requirements.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal;
Language Spoken:English,Chinese
