SUS304 Pineapple Juice Extractor , Ginger Industrial Juice Machine Screw Press
SUS304 Pineapple Juice Extractor , Ginger Industrial Juice Machine Screw Press
SUS304 Pineapple Juice Extractor , Ginger Industrial Juice Machine Screw Press
SUS304 Pineapple Juice Extractor , Ginger Industrial Juice Machine Screw Press
SUS304 Pineapple Juice Extractor , Ginger Industrial Juice Machine Screw Press
SUS304 Pineapple Juice Extractor , Ginger Industrial Juice Machine Screw Press
Specifications
Brand Name :
YGT
Model Number :
LZ/PLZ
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 sets
Price :
USD2000-usd10000
Payment Terms :
L/C, T/T
Supply Ability :
20 SETS PER MONTH
Delivery Time :
25 WORKING DAYS
Packaging Details :
plywood box
NAME :
screw juice extractor
Capacity :
500-2,000l/h
Application :
ginger, garlic, pineapple etc fruit with fiber
Material :
SUS304
Key word :
juice press, screw extractor
Structure :
by screw to press the fruit juice out
Description

Fruit Press juicer(could futher add crush unit together)

Application

The equipment is suitable to juice kinds of gingle, pineapple or fiber fruits and vegetable.

The juice rate reach 45%-65%(take apple as standard).

Usage

Use to process apple, pineapple, pear, vegetable etc fruit and vegetable to be juice.

Technical Parameters

Model Capacity T/H Power KW Sieve Mesh Size mm
LZ-0.5 0.5(apple) 1.5 ￠0.6mm 1560×450×1540
LZ-1.5 1.0(pineapple) 4 ￠0.6mm 1650×650×1740

The above data is according to different fruit to be customized

Equipment structure and working principle

The working principle: The main structure is the crushing device which installed above the the inlet hopper.There are four group running knife and one group stationary knife. Running knife cut the fruit by rotating with axis to 2-5mm piece and then into the spiral juicing part directly to make juice.The crushing part take the function of improving the juice rate. The main structure of the juicer is the helix,the helix diameter is more and more big and screw pitch is less and less small near dreg hopper. While the material impelled by helix,as the pressure existing,the material which after crushing get broken.The direction of helix is clockwise as the arrow direction. Add the material from inlet hopper and pressed by the helix.The juice then flow to the collection tank at the bottom and dreg expel from the outlet on the right. When the gar decrease and the dregs rate will reduce. But when the volume of the gar is too small, granular of dregs will be extrude through the filter with juice. So the magnitude of the gar depends on the demand of client’s cleaned on technology.
