UL Standard Flexible Armored Cable , Connection Electronic Polyvinyl Chloride Wire
UL Standard Flexible Armored Cable , Connection Electronic Polyvinyl Chloride Wire
Specifications
Brand Name :
UNI-CABLES
Model Number :
600V Hook Up
Certification :
CCC,ISO9001,UL1581
Place of Origin :
CHINA
MOQ :
100 Rolls
Price :
Depends on Quantity
Supply Ability :
10000 Rolls per Week
Packaging Details :
100 Meters per Roll
Rated Voltage :
600 V
Temperature Rating :
105°C
Insulation Colour :
Black Blue Brown Green Grey Yellow White Violet Pink
Conductor :
Tinned or bare, stranded or solid copper
Insulation :
PVC (Polyvinyl Chloride)
Description

600V Hook Up Wire PVC Electrical Cable UL Standard Internal Connection Wire

UL Standard Flexible Armored Cable , Connection Electronic Polyvinyl Chloride Wire

APPLICATION

For general purpose internal wiring of electronic and electrical equipment, where exposed to oil at a temperature not exceeding 60°C or 80°C. Uniform insulation thickness of wire to ensure easy stripping and cutting. Resistant to acids, alkalis, oils, moisture and fungi.

CABLE STANDARDS

UL 758, UL 1581, CSA C22-2, UL VW-1, CSA FT1

DIMENSIONS

Size COND.
TYPE		 CONDUCTOR INSULATION MAX
RESISTANCE
AT 20°C		 MIN. INSULATION
RESISTANCE AT 20°C
ohms/km		 DIELECTRIC
STRENGHT
AC 1MIN
V
SPEC
AWG		 NO.
mm		 NOMINAL
DIAMETER
mm		 NOMINAL
THICKNESS
mm		 OVERALL
DIAMETER
mm
30AWG Stranded Conductor 30 7/0.1 0.3 0.79 1.88±0.1 354.24 15 1500
28AWG 28 7/0.127 0.38 0.79 1.96±0.1 223.75
26AWG 26 7/0.16 0.48 0.79 2.06±0.1 136.73
24AWG 24 11/0.16 0.61 0.79 2.19±0.1 93.3
22AWG 22 17/0.16 0.76 0.79 2.34±0.1 55
20AWG 20 26/0.16 0.94 0.79 2.52±0.1 34.6
18AWG 18 41/0.16 1.18 0.79 2.76±0.1 21.8
16AWG 16 26/0.254 1.49 0.79 3.07±0.1 13.7
14AWG 14 41/0.254 1.88 0.79 3.46±0.1 8.62
12AWG 12 65/0.254 2.37 0.79 3.95±0.1 5.43
10AWG 10 105/0.254 3.4 0.79 4.98±0.1 3.41
10AWG 10 49/0.37 3.38 0.79 4.96±0.1 3.41
8AWG 8 168/0.254 4.3 1.15 6.6±0.2 2.16
6AWG 6 266/0.254 5.46 1.52 8.5±0.2 1.39
28AWG Solid
Conductor		 28 1/0.32 0.32 0.79 1.9±0.1 227.39 15 1500
26AWG 26 1/0.404 0.404 0.79 1.98±0.1 142.79
24AWG 24 1/0.511 0.511 0.79 2.09±0.1 89.39
22AWG 22 1/0.813 0.643 0.79 2.22±0.1 54.3
20AWG 20 1/1.29 0.813 0.79 2.39±0.1 33.9
18AWG 18 1/1.024 1.024 0.79 2.6±0.1 21.4
16AWG 16 1/1.29 1.29 0.79 2.87±0.1 13.5

UL Listed.
