Full Automatic Stator Winding Machine with Two Working Station Two Poles
Full Automatic Stator Winding Machine with Two Working Station Two Poles
Full Automatic Stator Winding Machine with Two Working Station Two Poles
Full Automatic Stator Winding Machine with Two Working Station Two Poles
Full Automatic Stator Winding Machine with Two Working Station Two Poles
Full Automatic Stator Winding Machine with Two Working Station Two Poles
Full Automatic Stator Winding Machine with Two Working Station Two Poles
Full Automatic Stator Winding Machine with Two Working Station Two Poles
Specifications
Place of Origin :
China
Brand Name :
Nide
Certification :
None
Model Number :
ND-SW-2
MOQ :
1set
Price :
Negotiable
Packaging Details :
Wooden case suitable for sea transportation
Delivery Time :
55 days
Payment Terms :
T/T, L/C
Name :
Stator winding machine
Color :
Customized
Working station :
2
Wire diameter :
0.25~0.8mm
Air pressure :
0.4~0.7MPa
Voltage :
AC380V,50/60Hz
Weight :
1800Kgs
Dimension :
2100*1250*1830mm
Description

Full Automatic Stator Winding Machine with Two Working Station Two Poles ( Winder )

Quick Detail:

1. Model No.: ND-SW-2
2. This machine has two working station.
3. Easily to change the fixture for different types of stators.
4. It could adapt to different requirement of different stator models.
5. It can wind two stators at same time.

Description:

This Automatic stator winding machine could wind two stators at same time. Fixtures are in cycle operation automatically. No need to assemble fixture on the stator. It is benefit for the on-line operation

Function:

1. Cast iron or steel frame can absorb the shock. Accuracy is stable. The maximum winding speed is up to 450rpm (according to the wire diameter).

2. All the actions are fully automatic (including loading and unloading). The winding could be more stable and efficient.

3. The cutting part structure is in compact. Wire clamping and cutting is finished at the same time.

4. Easily to change the fixture for different types of stators.

5. Fixtures are in cycle operation automatically.It is benefit for the on-line operation.

6. Permanent magnet tensioning device enables the tension adjustment.

7. Travel and swing angle is adjusted within 150-220mm (mechanical adjustment) .It could adapt to different requirement of different stator models.

8. Two working stations

Parameter:

Stator O.D

50~90mm

Wire diameter

0.25~0.8mm

Stator stack length

20~45mmm(standard);30~60mm(lengthen)

Stator I.D

30~50

Slot number

2 poles

Air pressure

0.4~0.7MPa

Lubrication mode

Continuous lubrication oiling machine

Voltage

AC380V,50/60Hz

Weight

1800Kgs

Dimension

2100*1250*1830mm

Competitive advantages:

It can wind two stators at same time. Easily change the fixture for different types of stators.

Full Automatic Stator Winding Machine with Two Working Station Two PolesFull Automatic Stator Winding Machine with Two Working Station Two Poles
