Easy To Install Galvanized Hy-Rib Concrete Formwork Cement Formwork Systems

Product Description

Product Specification

Product Advantages:

Easy placement, alignment, shoring and fixing of panels;

Easy creation of openings (doors and windows);

Easy insertion of rebar reinforcement (if necessary);

Easy placement of conduits for electrical and plumbing;

Easy visual inspection of the concrete pour;

Easy last minute changes;

Easy cladding or coating of any types of finishing.

Possibility to place the upper slab formwork before concreting the walls;

Possibility to pour all the walls of one complete floor in one pass;

Possibility to build non-repetitive constructions at low cost;

No need for anti-cracking welded wire;

No stripping or shutter rotation;

No need to place edge formwork.

Want to know more Product details?

Cement Pouring formwork structure COMPOSITION:

The two sides weight 11 kg/m2. It is composed of:

Rib Lath

Expanded metal with rib produced from commercial quality cold rolled and hot galvanized steel in accordance with ASTM C 847.

0.5 mm thickness.

C-Profiles

Produced from commercial quality cold rolled and hot galvanized steel in accordance with ASTM C 847.

0.6 mm thickness.

Connectors

Made from steel in coil grade B DIN 17 223 or equivalent.

20 mm width.

1.5mm thickness.

Longitudinal Rebar

Made from Fe 400 (French Norm) or equivalent.

500 N/mm2 elasticity limit.

700 N/mm2 traction strength.

5 mm diameter (minimum).

COMPANY:

Founded in 2000, located in ANPING COUNTY, CHINA.

Covering an areas of 20000 sqm ,specialized in architectural decorative mesh , construction building mesh , SS 304 fine filter mesh, walkway grating products.
With more than 15 years rich experience in this field . Velp has adopted modern management systems to ensure product quality.
Mainly markets: Australia, Germany ,France ,UK, Spain, Sweden ,Switzerland , Norway,Italy ,USA ,Canada ,Brazil, Panama, Middle East ,Southeast Asia.
We sincerely believe that with superior products ,reasonable price and comfortable services. That we can cooperate well with every customer.

Show details pictures:
