Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Hy Rib Concrete Cement Pouring Formwork System Mesh
Specifications
Brand Name :
Velp
Model Number :
Cement formwork system
Certification :
SGS CE ISO 9002
Place of Origin :
China
MOQ :
50sqm
Price :
USD2-3/SQM
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20000sqm/week
Delivery Time :
10-15 days
Packaging Details :
waterproof paper + wooden pallet
Material :
Galvanized steel
Size :
1.1*3m or customized
Weight :
11kg/sqm
Rib lath :
0.4mm thickness
C profiles :
0.6mm thickness
Connectors :
1.5mm thickness 20mm
Rebar :
5mm diameter,700 N/mm2 traction strength.
Feature :
Long lasting,enhance strength,light weight,Save time
Application :
Swimming pools,Tunnels,Waste water treatment plants
Description

---Product introduction

Hy-Rib is a high-ribbed, sacrificial formwork solution engineered for superior performance in large-scale concrete construction. Made from galvanised expanded metal mesh, Hy-Rib ensures durability and structural reliability while simplifying the construction process. Its unique ribbed design promotes excellent aggregate interlock, delivering enhanced joint strength and long-lasting concrete durability.

This versatile formwork system is suitable for both horizontal and vertical placements and eliminates the need for extensive surface preparation, such as scabbling. Its high visibility during concrete pours enables precise visual monitoring, reducing the risk of voids and honeycombing. Hy-Rib optimises labour efficiency, minimises formwork pressure, and accelerates the pouring process, providing economic advantages to construction projects.

-- Feature : SIMPLE, FAST AND COST EFFECTIVE

1. The formwork is very lightweight,about 11kg/sqm, It can easily be carried by 1-2 workers.

2.The formwork is cost effective compared to other construction systems.

3.There is no limitation of wall height or number of floors.

4.It is primarily used for building walals in all types of construction.

5.It remains in the construction to reinforce it after the concrete is poured.

After the panel placed,concrete is poured inside,excess water is eliminated by gravity through the grids.The fluid concrete becomes semi solid decreasing pressure against the grids.

6. The panel is 2-3 times faster than other traditional construction systems.

7. Every step of the construction process is simplified.

Material Galvanized steel
Size 1.1m*3m or customized
Weight 11kg/sqm
COMPOSITION Rib lath,C profile,Connector,Rebar
Application

Swimming pools,Tunnels,Waste water treatment plants
Feature Long lasting,enhance strength,light weight,Save time
