Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design
Specifications
Use :
Truck Trailer
Type :
Semi-Trailer
Material :
Steel
Size :
customised
Max Payload :
30-100T
Place of Origin :
CHINA
Brand Name :
AOTONG
Axle :
2 Axles*5TONS
Tire :
4 PCS
Function :
Farm tractor used
Color :
Custom's Requirement
Certification :
ISO,CCC
Packaging Details :
In nude,Polish with water wax before shipment
1 By 40ft/45ft/40fr container
2 By bulk /roro ship
3 As your requirments.
Professional package saves freight cost for customers
Guarantee the firmness and safety of the goods
Port :
Tianjin/ Lianyungang/Qingdao/Shanghai port
Supply Ability :
200 Set/Sets per Month
MOQ :
1 UNIT
Price :
$8,500.00/sets 2-5 sets
Delivery Time :
25 days
Payment Terms :
TT
Description

mini size tractor 15tons 2 axles hydraulic dump trailer with draw bar

1-trailer series

WELCOME TO JUYUAN

Product Information

Product

side wall semi trailer

Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design

Brand Name

Aotong Brand

Announcement (batch)

229

Place of Origin

Shandong province, China

Color

Any color will be available

Manufacturer

Liangshan Juyuan special vehicle manufacturing Co., Ltd

Specifications

Parameter

Outside Dimensions (L*W*H)

(6000-17000)*2500*1550mm

Rated Load

45000 kg

Tare Weight

7000 kg

Wheel Base

8390+1310+1310 (mm)

Twist lock No

12

Running Gear

Tires

specification

12R22.5-18

No. of tires

8/12/16

Spare tire carriers

1 or 2

Axles

Brand

FUWA (BPW optional)

No. of axles:

2/3/4

Axle-load

13000kg

Wheel rim

7.50-20 rim or 8.00

Suspension

rigid suspension,10 pcs leaf-spring

Brakes

brand

TKL brand

Brake chamber

double air chamber

System

Dual line braking system /ABS

Under Frame

Departure Angle

16

Front/Rear Overhang

1890mm

Main Beam

material

I beam ,Q345B, automatic submerged arc welded

specification

Height is 500mm,upper plate is 14mm,lower plate is 16mm,middle is 8mm

Cross Beam material

Q235B

Side beam

Channel steel

Plate form

Steel Sheet 3mm thickness or diamond plate(Also can choose other thickness ,such as 2mm,2.3mm,4mm,5mm,6mm)

King Pin

50# or 90#

Landing gear

28Ton

Accessory

One tooling box with a set of standard trailer tool

Electrical

Voltage

24V

Receptacle

7 ways (7 wire harness)

Lights

Front corner marker lamp :red ;reflector lamp :white

Side marker :orange

Rear lamp :red; rear reflector :white; turn single lamp :orange

Painting ,marking and side guard can according to the customer’s requirement

Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised DesignFarm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design

Related Products

Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design

Company Information

Farm Tractor 15T 2-Axle Hydraulic Dump Trailer with Draw Bar Customised Design

Factory strength:

Production Machinery:

Machine Name Brand & Model No. Quantity Number of Year(s) Used Condition
CNC Flame Plasma Cutting Machine GS 2 4.0 Acceptable
Press Machine JC21-160 4 4.0 Acceptable
Hydraulic Plate Bender WC67Y-200/4000 2 3.0 Acceptable
Hydraulic Pendulum Plate Shears QC12Y-12*3200 2 3.0 Acceptable
Drilling Machine with Jointed Arm ZN3050*16 4 4.0 Acceptable
Shaping Machine BS6065 2 4.0 Acceptable
Universal Rotary Milling Machine X6232 1 4.0 Acceptable
CNC Lathe EL6140N 2 4.0 Acceptable
Saw Machine GD4028N 2 5.0 Acceptable
Expander ZX-3000 1 3.0 Acceptable
Rolling Machine W11-4-200 2 3.0 Acceptable
Automatic Round Welding Machine W11SNC-10-6500 1 4.0 Acceptable

Testing Machinery:

Machine Name Brand & Model No. Quantity Number of Year(s) Used Condition
Vernier Caliper 0.02 mm 2 3.0 Acceptable
Ultrasonic Thickness Gauge SMART SENSOR 1 3.0 Acceptable
Sound Level Meter AZ8928 1 3.0 Acceptable
