Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Specifications
Brand Name :
AOTONG
Certification :
ISO,CCC
Place of Origin :
CHINA
MOQ :
1 UNIT
Payment Terms :
T/T
Delivery Time :
25 days
Packaging Details :
Export standard
Suspension :
Mechanical Or Air Suspension
Tyre Specifications :
12R22.5
Main beam :
Heavy duty I beam.
Kin pin :
2’’/3.5’’ bolt type
Braking system :
Double air chamber ,brake valve,45L air tanks ;ABS optional
Electrical :
LED light , 7 ways ,24V
Painting :
Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
Description


Fence Cargo Semi Trailer(Customerize and OEM Service Available)
Application
Coal/ Livestock/Vegetable/Cargo Loading
Product Name
2 axles fence semi trailer
3 axles fence semi trailer
4 axles fence semi trailer
Size
9500/11000*2500*2800/3800 (mm)
12500/13000*2500*2800/3800 (mm)
12500/13000*2500*2800/3800 (mm)
Payload
30-60Ton
30-80Ton
40-100Ton
Main beam
Height: 500mm, upper plate is 12mm, middle plate is 6mm, down plate is 14mm ; Material is Q345B Steel.
Height: 500mm, upper plate is 16mm, middle plate is 10mm, down plate is 18mm ; Material is Q345B Steel.
Height: 500mm, upper plate is 18mm, middle plate is 12mm, down plate is 20mm ; Material is Q345B Steel.
Axles
2*13T/16Ton/ FUWA/BPW/Other
3*13T/16Ton/FUWA/BPW/Other
4*13T/16Ton
/ FUWA/BPW/Other
Side Wall Height
600mm-1700mm (can be customized)
Side beam
16mm channel steel (Material is Q235B steel)
Bottom Platform
3mm checquered steel plate
Suspension
Mechanical suspension (Air suspension optional)
Leaf spring
90(width)mm*13(thickness)mm*10 layer(especial for exporting market)
Tire
12R22.5 / 11.00R20 8/12pcs (Other size optional)
Rim
9.00-22.5 / 11.00R20 8/12pcs (Other size optional)
Kin pin
Jost brand 2.0 or 3.5 inch
Landing gear
Jost brand 28Ton two speed
Braking system
Wabco re 6 relay valve; T30/30+T30 spring brake chamber; two units of 45L air tanks
Electrical
LED light , 7 ways ,24V
Tool box
One piece 1m *0.5m*0.5m ( size can be customized)
Twist locks
Optional
ABS
Optional
Painting
1.Sand blasting processing clean rust.2.Coat of anticorrosive primer.
3.Coats of finish urethane paint.
4.Color as customer choice.
Shipping terms
By bulk vessel, RORO, or 40HQ container

Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres

Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres Fence Semi Trailer with Mechanical or Air Suspension 12R22.5 Tyres
Frequently Asked Questions
Does your company have your own factory?

Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.

What is your minimum order quantity?

One unit.

Can you satisfy my special requirements?

Absolutely! We can customize trailers according to your specific requirements.

What logistics methods do you offer for transportation?

We provide multiple transportation options:

  • Primary method: Shipping by container or ro-ro/bulk vessel
  • For neighboring countries: Road or rail transport
  • For urgent spare parts: Express shipping via DHL, TNT, UPS or FEDEX


Do you offer any additional services?

Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.

Contact Us

Send your inquiry to begin our partnership. Our expert team is ready to assist you throughout the process.

Email: juyuan@aotongtrailer.com
Phone: +86 139 6962 7783

With over 30 years of trailer manufacturing experience, we've earned your trust through quality and reliability.
