3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume
Specifications
Brand Name :
AOTONG
Certification :
ISO,CCC
Place of Origin :
CHINA
MOQ :
1 UNIT
Payment Terms :
T/T
Delivery Time :
25 days
Packaging Details :
Export standard
Suspension :
Mechanical Or Air Suspension
Tyre Specifications :
12R22.5
Main beam :
Heavy duty I beam.
Kin pin :
2’’/3.5’’ bolt type
Braking system :
Double air chamber ,brake valve,45L air tanks ;ABS optional
Electrical :
LED light , 7 ways ,24V
Painting :
Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
Description

Weight&Dimension
1
Overall Dimension
10500*2500*4000mm
2
Curb Weight
9000kg
3
Loading Capacity
40000kg
4
Volume of Tank
20-60 CBM Customized
Chassis
1
Main Beam
2pcs, Material T700, tensile strength 700MPa, "工" shape, Thickness: upper board "--" 12mm, middle board "I " 10mm, bottom board "_" 16mm.
2
Side Beam
Channel steel
3
Cross Beam
Channel steel, 4mm Thickness
4
Suspension
Mechanical Suspensions/Air Suspensions
5
Leaf Spring
10-layers leaf spring
6
Tire
11.00R20/12.00R20/ 12R22.5
7
Rim
7.5 x 19.5
8
King Pin
2"(50mm)or3.5"(90mm)
9
Axle
3x16tons standard axles with cast hubs
10
Landing Gear
28T*2
Body
1
Tank Body Thickness
4mm
2
Tank Ends Thickness
5mm
3
Manhole
Diameter 500mm
4
Valves
Factory Standard
5
Shape
Elliptical, circular type shape
6
Compartments
1-9 silos
7
Discharge vale
4" API Adaptor Valve or 3" Spherical Valve
8
Bottom valve
3", 4" Contral by Pneumatic Block
9
Engine
Diesel engine with fuel tank, Changchai Brand, 8.8kW
10
Air Compressor
Bohai Brand
Braking&Electric System
1
Electric System
24V, with all LED lights
2
Braking System
Air brake, 8 chambers,air reservoir 2 pcs
Others
1
Tool Box
1 Tool Box
2
Spare Wheel Rack
1 Spare Tire Rack
3
Painting
Sand blasting, prime coating, surface painting,color optional, wax polishing
4
Color
According to customer's requirement

3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume

3 Axle LNG LPG Tank Trailer 40T Capacity 60CBM Volume

Frequently Asked Questions
Does your company have your own factory?

Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.

What is your minimum order quantity?

One unit.

Can you satisfy my special requirements?

Absolutely! We can customize trailers according to your specific requirements.

What logistics methods do you offer for transportation?

We provide multiple transportation options:

  • Primary method: Shipping by container or ro-ro/bulk vessel
  • For neighboring countries: Road or rail transport
  • For urgent spare parts: Express shipping via DHL, TNT, UPS or FEDEX


Do you offer any additional services?

Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.

Contact Us

Send your inquiry to begin our partnership. Our expert team is ready to assist you throughout the process.

Email: juyuan@aotongtrailer.com
Phone: +86 139 6962 7783

With over 30 years of trailer manufacturing experience, we've earned your trust through quality and reliability.
