3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars
Specifications
Brand Name :
AOTONG
Certification :
ISO,CCC
Place of Origin :
CHINA
MOQ :
1 UNIT
Payment Terms :
T/T
Delivery Time :
25 days
Packaging Details :
Export standard
Suspension :
Mechanical Or Air Suspension
Tyre Specifications :
12R22.5
Main beam :
Heavy duty I beam.
Kin pin :
2’’/3.5’’ bolt type
Braking system :
Double air chamber ,brake valve,45L air tanks ;ABS optional
Electrical :
LED light , 7 ways ,24V
Painting :
Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
Description
Details Images
The car carrier semi trailer are specially designed for transporting cars. There are three models according to the structural form of the car, respectively, double bridge with two tyres, double bridge with one tyre, single bridge with two tyres; according to the appearance is divided into skeleton type, semi-closed type, closed type. Skeleton type car carrier semi trailer is light weight, low cost and low fuel consumption Semi-closed car carrier semi trailer with tarpaulin on both sides can protect the car, and can transport other goods The car carriersemi trailer can be made into different lengths according to customers' demands, the side frame is welded I-beam, and the whole body is fully automatic submerged arc welding and carbon dioxide gas shielded welding. . After the welding is completed, shot blasting treatment is carried out to eliminate welding stress and improve the adhesion of the paint surface, so that the quality is stable and the appearance is beautiful. The car carrier semi trailer is a double-deck loading platform structure, the upper loading platform can be lifted up and down under the action of the lifting device to facilitate loading. We can meet different transportation needs according to customer requirements
Car Carrier Semi Trailer
Overall Dimension
15000mm*260mm*3000mm
Pay Load
For 7-10cars
Function
For car/vehicle transportation
Main Frame
350mm height l beam,Top Flange 10mm,Middle
Floor
3mm thickness
Axle
FUWA,BPW axle oroptional upon choice
Traction Pin
JOST 3.5"(90mm)
Landing gear
JOST 25T
Tire
11.0OR22.5
Spare Wheel Carrier
one set of spare wheel& tire carrier including a riser
Braking system
Dual line-air brake, piggyback spring on all axles;
four units of T30/30 spring brake chamber;
four lifting hydro-cylinder;
Three aircraft jump frames.
Electrical System
One unit of POWAY,24V 7-pin ISo1185 standard socket;
Standard Tail lamp with turn signal, brake light &reflector,
Side lamp etc.One set of 6-core standard Cable
Painting
Sand blasting processing on rustproof protection.
one coat of anticorrosive primer,two coats of finish urethane paint,Color as customer choice.

3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars

3 Axles Double Deck Car Carrier Semi Trailer 15000mm for 7-10 Cars

Frequently Asked Questions
Does your company have your own factory?

Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.

What is your minimum order quantity?

One unit.

Can you satisfy my special requirements?

Absolutely! We can customize trailers according to your specific requirements.

What logistics methods do you offer for transportation?

We provide multiple transportation options:

  • Primary method: Shipping by container or ro-ro/bulk vessel
  • For neighboring countries: Road or rail transport
  • For urgent spare parts: Express shipping via DHL, TNT, UPS or FEDEX


Do you offer any additional services?

Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.
