3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires
Specifications
Brand Name :
AOTONG
Certification :
ISO,CCC
Place of Origin :
CHINA
MOQ :
1 UNIT
Payment Terms :
T/T
Delivery Time :
25 days
Packaging Details :
Export standard
Suspension :
Mechanical Or Air Suspension
Tyre Specifications :
12R22.5
Main beam :
Heavy duty I beam.
Kin pin :
2’’/3.5’’ bolt type
Braking system :
Double air chamber ,brake valve,45L air tanks ;ABS optional
Electrical :
LED light , 7 ways ,24V
Painting :
Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
Description
Trailer Model
3 Axle Low bed Semi Trailer
Dimension(Lx W x H)(mm)
13000 x 3000 x 1750
Curb Weight(KG)
8000
Loading Weight( KG)
60000
Axle Brand
13TON Axle FUWA
Axle Number
3
Suspension system
Mechanical suspension
Ladder
mechanical
Chassis Frame
The height of the beam is 500mm, upper plate is 14mm, down plate is 16mm, middle plate is 8mm. Q345
Tire Specification and quantity
12R22.5 12units
Traction Pin
50# or 90#
Spare Wheel Bracket
2 pieces
Tool Box
1 Unit
Landing Leg
28 Ton
Brake system
Dual Line braking system
Brake air chamber
6 big air chambers
Electrical system
24V,7 Pole plug
Tail lamp with turn signal, brake light & reflector, side lamp etc.
One set 6-core standard Cable.
Colour
According to clients’ requirement
Packing
Polish with wax before shipping
Delivery way
Transfer to China port, and carry by bulk ship, the freight cost depends on the volume.

3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires

3 Axle Lowbed Semi Trailer 60T Capacity with 12R22.5 Tires

Frequently Asked Questions
Does your company have your own factory?

Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.

What is your minimum order quantity?

One unit.

Can you satisfy my special requirements?

Absolutely! We can customize trailers according to your specific requirements.

What logistics methods do you offer for transportation?

We provide multiple transportation options:

  • Primary method: Shipping by container or ro-ro/bulk vessel
  • For neighboring countries: Road or rail transport
  • For urgent spare parts: Express shipping via DHL, TNT, UPS or FEDEX


Do you offer any additional services?

Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.

Contact Us

Send your inquiry to begin our partnership. Our expert team is ready to assist you throughout the process.

Email: juyuan@aotongtrailer.com
Phone: +86 139 6962 7783

With over 30 years of trailer manufacturing experience, we've earned your trust through quality and reliability.
