Specifications
Brand Name :
AOTONG
Certification :
ISO,CCC
Place of Origin :
CHINA
MOQ :
1 UNIT
Payment Terms :
T/T
Delivery Time :
25 days
Packaging Details :
Export standard
Suspension :
Mechanical Or Air Suspension
Tyre Specifications :
12R22.5
Main beam :
Heavy duty I beam.
Kin pin :
2’’/3.5’’ bolt type
Braking system :
Double air chamber ,brake valve,45L air tanks ;ABS optional
Electrical :
LED light , 7 ways ,24V
Painting :
Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
Description
Skeleton semi-trailer is a large vehicle used for transporting goods. It consists of a tractor unit and a semi-trailer box. The box structure is relatively simple, usually with only one backboard and no fixed cargo compartments. The skeleton semi-trailer has the feature of being detachable, allowing for flexible assembly and disassembly according to the requirements of the cargo, adapting to different sizes and weights of goods transportation. This makes the skeleton semi-trailer a versatile and multi-purpose transportation tool, suitable for various types of cargo transportation, including but not limited to containers, timber, steel, and machinery equipment. The structural design of skeleton semi-trailer can effectively improve the load-bearing capacity, enabling it to carry larger sizes and weights of goods. Compared to other types of semi-trailers, the structure of the skeleton semi-trailer is more robust, with the ability to distribute and withstand the weight of the goods, enhancing transportation efficiency and safety.
Dimension
12500*2500*1600 (can be customized)
Payload
30-80T
Tare Weight
About 6.5T
Twist Lock
12 units
Main Beam
The height of the beam is 500 mm

upper plate is 14mm

down plate is 16mm

middle plate is 8mm
Axle number
3
Axle
13Ton Fuwa/BPW brand etc
King pin
#50 (2")/#90 (3.5") JOST/Other Brand
Suspension
Mechanical suspension / Germany type or America type / Air suspension
Leaf spring
90mm(W)*13mm(T)*10 Layer
Support legs
28Ton standard
Rim
9.0-20*12 pcs
Tire
235/75R17.5 / 245/70R17.5 / 245/70R19.5 8.25R20/8.25R16/11.00R22.5/12.00R22.5/10.00R20/11.00R20/12.00R20 brand can be optional
Other parts
1 tool boxs
Spare tyre holders
2
Electrical System
24V electrical system with LED light
Pictures and configuration information are for reference only.The final product can be made according to specific requirements.
