JL254A HPE Aruba Networking 2930F Switch Series HPE Aruba Networking 2930F 48G 4SFP+ Network Switch
JL254A HPE Aruba Networking 2930F Switch Series HPE Aruba Networking 2930F 48G 4SFP+ Network Switch
JL254A HPE Aruba Networking 2930F Switch Series HPE Aruba Networking 2930F 48G 4SFP+ Network Switch
JL254A HPE Aruba Networking 2930F Switch Series HPE Aruba Networking 2930F 48G 4SFP+ Network Switch
Specifications
Port Count :
48 ports
Model Number :
JL254A
Operating Temperature :
0°C to 40°C
Supply Ability :
200
Port Speed :
1 Gbps
Management :
Web GUI, SNMP, CLI
MOQ :
1
Delivery Time :
24-48 Hours
Power Consumption :
15W
Layer :
Layer 2/Layer 3
Payment Terms :
T/T,Western Union
Weight :
2.5 kg
PoE Support :
Yes, up to 30W per port
Switching Capacity :
48 Gbps
Price :
Negotiation
Warranty :
1 year
Dimensions :
440 x 220 x 44 mm
Certification :
CE, FCC, ROHS, CCC, ISO9001
Forwarding Rate :
35.7 Mpps
Brand Name :
HPE ARUBA
Power Supply :
370W
MTBF :
500,000 hours
Place of Origin :
CHINA
VLAN Support :
Yes, up to 4096 VLANs
Description

JL254A HPE Aruba Networking 2930F Switch Series HPE Aruba Networking 2930F 48G 4SFP+ Network Switch

The HPE Aruba Networking 2930F Switch Series is designed for digital workplaces optimized for mobile users. These powerful Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like HPE Aruba Networking ClearPass Policy Manager, HPE Aruba Networking Management Software (AirWave) and cloud-based HPE Aruba Networking Central. HPE Aruba Networking Virtual Switching Framework (VSF) provides stacking scale and simplicity for enterprise edge, SMB and branch offices. The 2930F series delivers performance and value with support for RIP routing, Access OSPF, 10GbE uplinks, up to 740W PoE+, robust QoS, and requires no software licensing.

The HPE Aruba Networking 2930F Switch Series is a family of Layer 3 stackable switches that are easy to deploy and manage, providing scale for enterprise, SMB and branch access networks

Simplify with Zero Touch Provisioning (ZTP) and cloud-based HPE Aruba Networking Central support

Scale with 8-member stacking

High-performance Access Layer Switches

  • The HPE Aruba Networking 2930F Switch Series provides performance, security, and ease of use optimized for the digital workplace with unified management tools such as HPE Aruba Networking ClearPass Policy Manager, HPE Aruba Networking Management Software (Airwave), and HPE Aruba Networking Central.
  • Robust Layer 3 feature set includes Access OSPF, static and RIP routing, ACLs, sFlow®, IPv6 with no software licensing required.
  • Up to 8-member stacking with HPE Aruba Networking Virtual Switching Framework (VSF) and convenient built-in 1GbE or 10GbE uplinks and PoE+ models deliver right-size network access performance.
  • Provides optimal configuration automatically when connected to HPE Aruba Networking access points for PoE priority, VLAN configuration, and rogue AP containment.
  • Supports multiple programmatic interfaces, including REST APIs and Openflow 1.0 and 1.3, to enable automation of network operations, monitoring, and troubleshooting.

Main Specification

Product Description HPE Aruba 2930F 48G 4SFP+ - switch - 48 ports - Managed - rack-mountable
Device Type Switch - 48 ports - L3 - Managed - stackable
Enclosure Type Rack-mountable 1U
Subtype Gigabit Ethernet
Ports 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
Performance Throughput: 112 Mpps Switching capacity: 176 Gbps Latency (1 Gbps): 3.8 µs Latency (10 Gbps): 1.6 µs
Capacity Jumbo frame size: 9220 IPv4 routing table entries: 10000 IPv6 routing table entries: 5000
MAC Address Table Size 32K entries
Routing Protocol OSPF, RIP, RIP-1, RIP-2, BGP, IGMPv2, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLD, CIDR
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, SNMP, Telnet, SNMP 3, SNMP 2c, SSH, SSH-2, CLI, XRMON
Features Flow control, full duplex capability, DHCP support, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, DiffServ support, IPv6 support, SNTP support, sFlow, STP support, MSTP support, ACL support, QoS, Jumbo Frames support, DHCP server, STP Root Guard, UDLD, LLDP support, LACP, MIB, MAC address lockout, dynamic ARP protection, DHCP protection, GVRP, MVRP, NDP, CoS, ToS, OpenFlow support, CPU protection, ICMP, ICMP IRDP, VXLAN, MIB II
Compliant Standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
Power AC 120/230 V
Dimensions (WxDxH) 44.25 cm x 24.63 cm x 4.39 cm
Weight 3.1 kg
Manufacturer Warranty Limited lifetime warranty


General

Device Type Switch - 48 ports - L3 - Managed - stackable
Enclosure Type Rack-mountable 1U
Subtype Gigabit Ethernet
Ports 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
Performance Throughput: 112 Mpps Switching capacity: 176 Gbps Latency (1 Gbps): 3.8 µs Latency (10 Gbps): 1.6 µs
Capacity Jumbo frame size: 9220 IPv4 routing table entries: 10000 IPv6 routing table entries: 5000
MAC Address Table Size 32K entries
Routing Protocol OSPF, RIP, RIP-1, RIP-2, BGP, IGMPv2, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLD, CIDR
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, SNMP, Telnet, SNMP 3, SNMP 2c, SSH, SSH-2, CLI, XRMON
Encryption Algorithm MD5, SSL
Authentication Method RADIUS, PAP, CHAP, TACACS, TACACS+
Features Flow control, full duplex capability, DHCP support, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, DiffServ support, IPv6 support, SNTP support, sFlow, STP support, MSTP support, ACL support, QoS, Jumbo Frames support, DHCP server, STP Root Guard, UDLD, LLDP support, LACP, MIB, MAC address lockout, dynamic ARP protection, DHCP protection, GVRP, MVRP, NDP, CoS, ToS, OpenFlow support, CPU protection, ICMP, ICMP IRDP, VXLAN, MIB II
Compliant Standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX
Processor 1 x ARM Cortex-A9: 1.016 GHz
RAM 1 GB DDR3 SDRAM
Flash Memory 4 GB

Expansion / Connectivity

Interfaces 48 x 1000Base-T RJ-45 4 x Gigabit / 10Gbit LAN SFP+ 1 x serial (console)
Expansion Slots 1 (total) / 1 (free) x Expansion Slot
Installed Modules Qty (Max) 0 (installed) / 4 (max)

Power

Power Device Internal power supply
Installed Qty 1
Voltage Required AC 120/230 V
Power Consumption Operational 46.6 watt
80 PLUS Certification 80 PLUS Silver

Miscellaneous

Included Accessories Mounting screws, 4 mounting ears, 4 bumper feet, cable tie
Compliant Standards CISPR 22 Class A, CISPR 24, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, ICES-003 Class A, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1-07 Second Edition, VCCI Class A, IEC 60825-1:2007, CNS 13438, EN 55024:2010, EN 55022:2010, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 60825-1:2007, FCC CFR47 Part 15 A, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013

Software / System Requirements

Software Included Command Line Interface (CLI), HP Web browser, HP Intelligent Management Center

Dimensions & Weight

Width 44.25 cm
Depth 24.63 cm
Height 4.39 cm
Weight 3.1 kg

Manufacturer Warranty

Service & Support Limited warranty - lifetime

Environmental Parameters

Min Operating Temperature 0 °C
Max Operating Temperature 45 °C
Humidity Range Operating 15 - 95% (non-condensing)
Min Storage Temperature -40 °C
Max Storage Temperature 70 °C
Humidity Range Storage 15 - 90% (non-condensing)
