10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
10 MHz - 6 GHz Fpv Uav DJI Signal Identification Module Automatic Detection 5 km
Specifications
Payment Terms :
T/T
Weight :
3.5 kg
Model Number :
DB01
Output Type :
Analog Voltage
Certification :
CE
Frequency Range :
10 MHz - 6 GHz
MOQ :
1
Delivery Time :
7-10 working days
Interface :
Analog Output / Digital Output
Price :
$3,999/pc~$45,00/pc
Sensitivity :
-80 dBm
Supply Ability :
<500 pcs 10 working days
Dimensions :
30 cm x 20 cm x 15 cm
Brand Name :
Roviyno
Product Name :
RF Detection Module
Packaging Details :
Carton box
Place of Origin :
China
Detection Distance :
Up to 10 meters
Description
Automatic Detection Trajectory Tracking Fpv Uav DJI Signal Identification Module
Item Spotlights
  • 5 km Stable RF Drone Detection
  • DJI O4 Protocol Decoding & Localization
  • <5 m Drone & Pilot Positioning Accuracy
  • Protocol Decoding & RF Fingerprint Recognition
  • Drone ID, Serial Number & Telemetry Output
  • TTL Serial Output for Easy OEM Integration
  • 5 V Power Supply, Typical Power Consumption <4 W
  • Remote Firmware Upgrade Supported
Product Specification
Item Specification
DJI O3 Decoding Outputs drone, pilot, and home location, along with serial number and drone model.
DJI O4 Decryption Support Outputs 176 encrypted bytes; supports decryption via server interface to obtain drone, pilot, and home location, and serial number
High-Performance Processing 61.44M sample rate with FPGA-based processing, delivering powerful DJI detection capability
DJI Detection Range 2 km-20 km
RID Compliance Supports GB42590-2023 and ASTM F3411-22a standards
On-Device Processing All signal processing and decoding are completed on the device with direct result output
RID Detection Range 1 km-5 km
Communication Interfaces Supports UDP / TCP and TTL serial (3.3V, 115200)
Power Supply 5V
Power Consumption 3.3W
Dimensions 89 mm x 55 mm x 18 mm
