2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
Specifications
Angle :
Full 360° (All- Airspace)
Input Connector Type :
N-J (Embedded)
Transport Package :
Carton
Specification :
660x360x340mm
Origin :
China
Package Size :
60.00cm * 36.00cm * 34.00cm
Package Gross Weight :
0.550kg
Weight :
500g
Frequency :
2.4G
Function :
Amplify The Distance of The Anti-Drone Module
Samples :
US$ 15/Piece 1 Piece(Min.Order) |
Customization :
Available | Customized Request
Place of Origin :
Guangdong, China
Brand Name :
LDSK
MOQ :
2 piece
Delivery Time :
5-8 workdays
Payment Terms :
D/A, D/P, T/T, Western Union, MoneyGram， Paypal
Supply Ability :
5000pcs per month
Description

2.4G 8dBi N-J High Gain Omnidirectional Fiberglass Antenna 20*600mm for Return refunds

Parameters
Frequency Range 2400-2500MHz
Gain(dBi) 8±1dBi
VSWR ≤1.5
Polarization Vertical
Horizontal Beam width(0º) 360º
Vertical Beam width(0º) 17±3º
Ovality(dB) ±2dB
Input Impedance(Ω) 50Ω
Maximum input power(W) 50W
Input connector type N-J (embedded)
Lightning Protection DC Grounding
Dimensions­mm(Diameter * Length) 20*600mm
Packing size(mm) 660*360*340mm
Antenna weight(kg) 0.5±0.1KG
Rated Wind Velocity(m/s) 36.9m/s
Radome Color Black
Radome material Fiberglass
Operating temperature(ºC) -30~65º
Installation Method Machine mounting
2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
Product Description

2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type 2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type

Packing & Delivery
Quantity (sets)
> 500
> 1000
Others
Lead time (days)
7 days
about 7-14 days
Negociation

2.4G High Gain Omnidirectional Fiberglass Antenna Counter UAV 8dBi N-J Connector Type
