90/100HP farm tractor TT904/TT1004 4*4 4wheel drive Agricultural farm equipment
90/100HP farm tractor TT904/TT1004 4*4 4wheel drive Agricultural farm equipment
Specifications
Brand Name :
KATOP
Model Number :
TT904/TT1004
Certification :
CE
Place of Origin :
Shandong
MOQ :
8 units
Payment Terms :
L/C, T/T
Supply Ability :
300 UNITS per month
Delivery Time :
15 days
Packaging Details :
Iron frame in 20GP container
Engine :
YUCHAI 4102 TURBO
Power :
6.2KW (90HP)/73.5KW (100HP)
Driving Type :
4*4
Hydraulic Valve: :
2-Way Valve
Dimension :
4593x2050x2810mm
Clutch :
Dry-type, Double-acting
Gear box :
16F+8R
Size of Tire :
Front:11.2-24 Rear: 16.9-34
Wheel base :
2195mm
Min.Ground Clearance :
379mm
Description
MODEL TT904 TT1004
DRIVE TYPE 4x4 4x4
ENGINE
ENGINE YUCHAI 4102 TUOBO YUCHAI 4102 TUOBO
OIL TANK(L) 240 240
Rated speed (r/min) 2300 2300
ENGINE RATED POWER(kw) 66.2 73.5
MIN OIL CONSUPTION(g/kw·h) ≤242 ≤242
Minimum fuel consumption at full load( L/h) 13.91 15.44
TRANSMASSION
CLUTCH DRY , DOUBLE CLUTCH DRY , DOUBLE CLUTCH
PTO SPPED(rpm) 540/1000 or 760/1000(optional) 540/1000 or 760/1000(optional)
SHAFT 16F+8R 16F+8R
HYDRUALIC SYSTEM
HYDRUALIC VALVE 2-Way 2-Way
Three point linkage
lifting force at 610mm KN ＞16 ＞16

Technical parameters
Dimension LxWxH mm 4593x2050x2810 4593x2050x2810
WHEEL BASE(mm) 2195 2195
FRONT TREAD(mm) 1610 1610
REAR TREAD(mm) 1620-2020(usual 1620) 1620-2020 (usual 1620)
MIN GROUND CLEARENCE(mm) 379 379
FRONT TYRE 11.2-24 11.2-24
REAR TYRE 16.9-34 16.9-34
EXW $16250 $17940
