135W GaN Embedded Desktop AC/DC Power Supply: 15V 9A High-Current Solution

Product Overview

The 135W GaN Embedded Desktop AC Adapter is a high-performance power solution specifically engineered for the unique voltage and current requirements of sophisticated embedded architecture. By leveraging advanced Gallium Nitride (GaN) power semiconductors, this unit delivers a robust 15V 9A output with an industry-leading efficiency of up to 94%. It is the premier choice for Embedded Computing Systems, Industrial Motherboards, and Edge AI Hardware.

The GaN-driven architecture allows for a completely fanless, silent, and slimline design that maintains a cool operating temperature even under sustained heavy processing loads. Unlike traditional silicon-based adapters, this unit offers superior power density and ultra-fast transient response, ensuring that high-speed processors and FPGA modules receive stable, uninterrupted power during rapid computational spikes.

Key Specifications

Our 135W GaN series is built for computational integrity and long-term stability, offering a range of voltage configurations optimized for high-performance hardware.

• Input Voltage: 100-240V AC, 50/60Hz (Universal Global Input).

• Total Output Power: 135W Continuous Maximum.

• Common Output Configurations:

  • 12V Series: 12V 11.25A (135W Max - For high-current logic)

  • 15V Series: 15V 9A (135W Max - Embedded Standard)

  • 19V Series: 19V 7.1A (135W Max - For industrial computing/HMI)

  • 24V Series: 24V 5.62A (135W Max - For automation/control)

• Ripple & Noise: < 150mVp-p (Typical) – Ensuring clean power delivery to prevent logic errors and signal jitter in high-speed data buses.

• Industrial Safety Compliance: Fully compliant with IEC/EN/UL 62368-1 (IT & AV standard).

• GaN Efficiency: High-efficiency architecture meeting and exceeding Level VI standards.

• EMI/EMC Compliance: Meets Class B standards for low electromagnetic interference in sensitive laboratory and office environments.

• AC Inlet: IEC320-C14 (3-Pin grounded) or C6 (3-Pin "Mickey Mouse") for slim-profile setups.

• MTBF (Reliability): > 100,000 Hours, ensuring minimized downtime for critical 24/7 embedded systems.

Ideal Applications

The 135W GaN precision output is optimized for high-performance computing and data systems:

• Embedded Computing: High-performance industrial motherboards (Mini-ITX, COM Express), fanless embedded PCs, and SBCs (Single Board Computers).

• Edge AI & Machine Vision: AI inference modules, high-speed camera controllers, and automated vision inspection systems.

• Industrial IoT (IIoT): Intelligent gateways, multi-protocol routers, and high-capacity data concentrators.

• Test & Measurement: Portable diagnostic instruments and modular data acquisition (DAQ) hardware.

• Network Storage: Compact NAS units and specialized RAID controller enclosures.

Professional Safety & Reliability Suite

• GaN Thermal Management: GaN technology minimizes energy loss as heat, enabling a fanless, fully enclosed design that protects internal components from ambient dust and contaminants.

• Ultra-Fast Transient Response: Optimized to maintain a stable 15V output during the rapid CPU/GPU load swings typical of high-performance embedded computing.

• Advanced Ripple Suppression: Integrated multi-stage LC filtering significantly reduces high-frequency switching noise, protecting the integrity of sensitive analog-to-digital (ADC) converters and high-speed memory modules.

• Secure Connectivity: Available with standard 5.5x2.5mm DC jacks or locking 4-pin Power DIN connectors to prevent accidental disconnection in mobile or high-vibration environments.

• Comprehensive Protection: Active Over-Voltage (OVP), Over-Current (OCP), Over-Temperature (OTP), and Short-Circuit Protection (SCP) with intelligent auto-recovery features.
