96W Desktop AC Adapter: 24V 4A / 12V 8A Industrial-Grade Power Supply

Product Overview

The 96W Desktop AC Adapter is a flagship-level switching power supply designed for high-performance industrial control systems and professional display hardware. Delivering an impressive 4A at 24V or 8A at 12V, this adapter is built to sustain heavy, continuous loads without voltage deviation. Its advanced internal architecture features high-capacity industrial-grade capacitors and enhanced magnetic shielding to minimize electromagnetic interference (EMI) in sensitive environments. Housed in a heavy-duty, impact-resistant desktop enclosure with optimized thermal airflow, it provides a stable, grounded, and cool-running power source for 24/7 mission-critical applications, ensuring maximum uptime for industrial HMI panels, high-brightness displays, and sophisticated control arrays.

Key Specifications

The 96W series is engineered for global industrial standards, incorporating a full suite of safety protections including Over-Voltage (OVP), Over-Current (OCP), Over-Temperature (OTP), and Short-Circuit (SCP) recovery.

• Input Voltage: 100-240V AC, 50/60Hz (Universal Global Compliance)

• Total Output Power: 96W Maximum

• Output Voltage & Current Range:

  • 12V Series: 12V 7.5A, 12V 8A (90W-96W Max)

  • 15V Series: 15V 6A, 15V 6.4A (96W Max)

  • 19V Series: 19V 4.74A, 19V 5A (90W-95W Max)

  • 24V Series: 24V 3.75A, 24V 4A (90W-96W Max)

  • 36V Series: 36V 2.5A, 36V 2.66A (90W-96W Max)

  • 48V Series: 48V 1.87A, 48V 2A (90W-96W Max)

• Ripple & Noise: < 150mVp-p (Measured with 20MHz bandwidth)

• MTBF (Mean Time Between Failures): > 50,000 Hours at 25°C ambient temperature, full load

• AC Inlet: IEC320-C14 (Standard PC-type) / C6 (Clover) / C8 (Figure-8) options

• DC Connector: Standard 5.5mm x 2.1mm / 2.5mm (Ultra-low resistance 16AWG or 14AWG copper DC cable)

• Energy Efficiency: Meet DoE Level VI / CoC Tier 2 standards

• Global Certifications: UL, cUL, CE, GS, TUV, UKCA, SAA, RCM, PSE, KC, KCC, CCC, CB, FCC, RoHS, REACH.

Ideal Applications

The 96W high-capacity output is the premier choice for power-hungry commercial and technical systems:

• Industrial Automation: HMI panels, PLC controllers, high-torque small motors, and automated production line sensors.

• Professional Displays: Large-format LCD/LED monitors, high-brightness digital signage, and multi-screen video walls.

• Computing & Storage: High-performance Mini-PCs, multi-bay NAS (Network Attached Storage), and laptop docking stations.

• Security & Surveillance: 16/32-channel NVR systems, high-power PTZ cameras, and sophisticated access control hubs.

• LED & Lighting: Professional studio LED panels, architectural lighting controllers, and high-density RGBW arrays.
