HD2461 1.2 N.M Automatic Torque Screwdriver High Speed Low Noise
HD2461 1.2 N.M Automatic Torque Screwdriver High Speed Low Noise
HD2461 1.2 N.M Automatic Torque Screwdriver High Speed Low Noise
HD2461 1.2 N.M Automatic Torque Screwdriver High Speed Low Noise
Specifications
Brand Name :
AND
Model Number :
HD2461
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
Before T/T ; L/C
Delivery Time :
1-4 weeks
Packaging Details :
Paper Box
Name :
Hand Hold Smart Screwdrivers
The power of motor :
DC 40W
Max. speed(rpm) :
1000
Rated torque（ N.m) :
1.2
Batch Head :
Hexagon (Hex)（6.35mm）
Description

Handheld Smart Screwdriver HD2461 High speed Low noise Comfortable using torque control
· Patented design
· Ergonomic grip, non-slip, comfortable and secure
· Efficient heat dissipation setting and ultra-low noise output
· High-performance servo motor and high-precision reducer power transmission mechanism
· High-precision angle sensor and two-color LED indication of lock attachment status
· Safety level in line with the relevant data of GB3883/IEC60745 and other standards

This is the hexagon bits model of HD2460. It has the same spcs like HD2460.

(0.2 to 1.2 N.m's torque out put range, 1000 circles per minute maximum running speed, 0.5 kg of weight)

Just like HD2460, HD2461 also has mounting plate available, if you need it, please contact our technical staff.

Specifications

ModelAdapted
controller		Tool cableTorque output rangeStart-up methodMaximum
Speed
(rpm)		Adapted outer diameter of screw(mm)Weight
(kg)
kgf.cmN.mlbf.inTrigger buttonMachine ScrewTapping Screw
HD2120ACT-H00XX
/HNA-H21XX		C113X
/C123X
/C124X		0.2～2.350.02～0.230.18～2.04√50001.0～2.31.0～2.00.4
HD2350ACT-H01XX
/HNA-H23XX		1.52～9.180.15～0.91.33～7.97√12001.4～3.01.4～2.60.5
HD2351ACT-H01XX
/HNA-H23XX		1.52～9.180.15～0.91.33～7.97√12001.4～3.01.4～2.60.5
HD2460ACT-H02XX
/HNA-H24XX		2.0～12.230.2～1.21.77～10.62√10001.4～4.01.4～3.00.5
HD2461ACT-H02XX
/HNA-H24XX		2.0～12.230.2～1.21.77～10.62√10001.4～4.01.4～3.00.5
HD2571ACT-H03XX
/HNA-H25XX		5.1～16.320.5～1.64.42～14.16√8002.0～5.02.0～4.20.6


Dimensions
HD2461 1.2 N.M Automatic Torque Screwdriver High Speed Low Noise
