Specifications
Brand Name :
AMG
Model Number :
Standard/Customized
Certification :
ISO9001
Place of Origin :
China
MOQ :
3
Delivery Time :
3-7 days for standard products/7-10 days for non-standard products
Price :
Request Quote
Name :
T Slot Milling Tools for Assembly Platforms
Type :
Customized
Coating :
TiAIN,DLC/ZrN/Super Finish Coating
Suitable for :
copper,STAINLESS STEEL,glass etc high hardness workpiece,semi finishing and roghing,Aluminum
Flute :
6 Flutes
Description
High Precision Carbide T Slot Milling Cutter 6 Flutes End Mill For Assembly Platforms
Product Attributes
Attribute Value
Name T Slot Milling Tools for Assembly Platforms
Type Customized
Coating TiAIN, DLC/ZrN/Super Finish Coating
Suitable for Copper, stainless steel, glass etc high hardness workpiece, semi finishing and roughing, aluminum
Flute 6 Flutes
Product Description

In the manufacturing process of basic components such as assembly platforms, automated equipment, and test fixtures, the machining of T-slots is very important that cannot be ignored. To help engineers finish this process more efficiently, AMG specializes in the introduction of the six-flute T-slot end mill, which has won the favor of many manufacturing enterprises due to its stable and precise performance.

Application Scope

It is widely used for precision milling of T-slots in components such as assembly platforms, workbenches, and fixture baseplates. It is particularly suitable for machining track installation slots, slider guide rail structures, and fastener chutes.

Specifications
Model Cutter Diameter D (mm) Shank Diameter d (mm) Cutter Length L1 (mm) Total Length L (mm) Number of Flutes
AMG-T6-12 12 10 20 75 6
AMG-T6-16 16 12 25 90 6
AMG-T6-20 20 16 30 100 6
High Precision Carbide T Slot Milling Cutter 6 Flutes End Mill For Assembly Platforms
High Precision Carbide T Slot Milling Cutter 6 Flutes End Mill For Assembly Platforms
Processing Principles

Through the coordination of the end edge and the side edge, the tool first cuts a straight groove on the surface of the workpiece and then continues to expand to form a "T"-shaped bottom groove. The six-groove structure ensures smooth chip removal and minimal vibration during machining, effectively improving surface finish and machining consistency.

Why Customers Choose This Milling Cutter
  • Six-blade structure ensures smoother cutting and higher processing efficiency
  • Strong chip evacuation design to reduce tool sticking and chip jamming
  • Compatible with multiple materials, with strong universality
  • Provide model selection advice and customized services, responding to non-standard requirements anytime
