1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
1920-2170MHz 10dBi Directional Wall Mount Antenna 3g outdoor antenna
Specifications
Place of Origin :
Shenzhen, China.
Brand Name :
AMEISON
Model Number :
AMXW-1922-10B
Certification :
RoHS and REACH Compliant by Exemption
Frequency range（MHz） :
1920-2170
Gain（dBi） :
10
VSWR :
≤1.5
Polarization :
Vertical
Lightning protection :
DC Ground
Input connector type :
SMA female or Requested
Mounting way :
wall-hanging or pole-holding
Mounting hardware（mm） :
￠35-￠50
Price :
FOB SHENZHEN
Packaging Details :
bubble PP bag or EPE/inner box/master carton(safe export packaging)
Delivery Time :
10 days
Payment Terms :
L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability :
80,000 Pieces per Month
MOQ :
500 pcs per item
Description

1920-2170MHz Directional Wall Mount Antenna

AMXW-1922-10B

Feature:

High gain

Strong anti-interference ability

Good defense system

Full day working

Exquisite appearance

Optimized dimension

Application:

3G system

Wireless communication and data transmission system

AMXW-1922-10B

Electrical Specifications

Frequency range(MHz)

1920-2170

Bandwidth(MHz)

250

Gain(dBi)

10

Half-power beam width(°)

H:60 V:45

VSWR

≤1.5

Input Impedance(Ω)

50

Polarization

Vertical

Maximum input power(W)

50

Lightning protection

DC Ground

Input connector type

SMA female or Requested

Mechanical Specifications

Dimensions-mm (Height/Width/Depth)

140*120*40

Antenna weight(kg)

0.29

Operating temperature(°c)

-40～60

Rated Wind Velocity-m/s

60

Radome material

ABS

Radome color

white

Mounting way

wall-hanging or pole-holding

Mounting hardware(mm)

￠35-￠50
