Solar Storage 12v 200ah Lithium Iron Lifepo4 Deep Cycle Battery UPS
Solar Storage 12v 200ah Lithium Iron Lifepo4 Deep Cycle Battery UPS
Specifications
Brand Name :
AMAXPOWER or OEM
Model Number :
HD12-200
Certification :
CE, IEC, ISO
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000000pcs/month
Delivery Time :
25~30days
Packaging Details :
By Carton Box Then onto Pallet
Type :
Storage Battery
Electrolyte: :
Gel
Nominal Voltage: :
12V
Nominal Capacity :
200Ah
Dimension :
522*240*216*240mm
Weight :
59kg
Terminal :
T4
Color :
Silver,Yellow,White,Black (OEM Customize Color)
Lifespan :
>15 Years
Warranty :
3 Years
Usage :
UPS, Electric Power, Lighting, Boat, EPS, Fire Alams, Security System
Application :
UPS, Electric Power, Lighting, Boat, EPS, Fire Alams, Security System
Battery Type :
Solar Battery,Gel Battery,Sealed Lead Acid Battery,Deep Cycle Gel Battery,UPS Battery,Storage Battery
Maintenance :
Free
Product Name :
12v 100ah deep cycle battery , 12v 200ah deep cycle battery
Description

China Gel Battery 12V 150Ah/200Ah Long Life Solar Storage Battery and UPS Storage Battery (12V 200Ah)

China Deep Cycle Gel Battery 12V 200Ah Solar Storage Battery for Power System and UPS System

AMaxpower HD Series sealed free maintenance AGM and GEL storage batteries. Our batteries are always in the process of innovation according to market and environment: AGM battery→GEL battery→High Temperature Long Life Deep Cycle GEL battery.

Super Life Deep Cycle Battery 12V 100Ah /120Ah/150Ah/200Ah/250Ah Best Good Quality Battery for OEM/ODM Customize

Key Features:

* Gelled electrolyte made by mixing sulfuric acid with silica fume.
* The electrolyte is gel like ,immobile and does not leak ,enabling uniform reaction of each part of the plate.
* High rate discharge performance due to tight assembly technology
* Strong heat dissipation and wide operating temperature range
* Avoid acid mist being separated out , environment friendliness
* Efficient venting system release excessive gas automatically

Deep cycle gel batteries are best choice for backup and frequent cycle discharge applications, such as:

♦EPS and UPS battery backup
♦Solar and wind energy storage system
♦Telecommunication Equipment
♦Power plant and transmission system
♦Signal system , emergency lighting system , security system

Specification

Nominal Voltage 12V (6 cells)
Nominal Capacity 200Ah@10 hour-rate
Dimension Length 522±2(20.6 inches)
Width 240±2(9.45 inches)
Height 216±2(8.50 inches)
Total Height 240±2(9.45 inches)
Weight Approx. 59kg (130lbs)
Reference Capacity (25°C/77°F ) 20 hour rate (10.5A) 210Ah
10 hour rate (20A) 200Ah
5 hour rate (36A) 180Ah
3 hour rate (53.3A) 160Ah
1 hour rate (130A) 130Ah
Max. Discharge Current (25°C/77°F) 1200A (5S)
Internal Resistance Full charged at 25℃(77°F): Approx. 3.8mΩ
Charge (Constant Voltage) (25°C/77°F)

Cycle Use

Voltage: 14.4-15.0V

Initial Charging Current: Less than 50A
Float Use Voltage: 13.6-13.8V
Operating Temperature Range Discharge -20~50°C
Charge 0~50°C
Storage -20~50°C
Nominal Operating Temperature Range 25°C ±3°C(77±3°F)

Capacity affected by Temperature

(20 hour rate)

 40°C(104°F) 102%
25°C(77°F) 100%
0°C(32°F) 85%
-15°C(5°F) 65%
Self-Discharge (25°C/77°F) After 3 month 91%
After 6 month 82%
After 12 month 64%
Container Material ABS Plastic

Applications

-Solar energy system -Aerial work platform

-Floor cleaning machine -Recreational vehicles

-Golf cart and Buggies -Control System

-Power Tools -UPS Systems

-Solar and Wind -Emergency Systems
