Specifications
Brand Name :
KLUK
Model Number :
KHD75
Certification :
ISO9001:2021;ISO14001:2021
Place of Origin :
GUANGDONG,CHINA
MOQ :
500 square meters
Price :
Negotiation
Payment Terms :
T/T, L/C, D/P
Supply Ability :
3000 square maters
Delivery Time :
25-30 days
Packaging Details :
Pearl cotton, foam cotton, wooden box,etc
Materials :
Aluminum Alloy 6063
Glass :
Tempered Laminated Double Glazed
Thickness :
1.0-2.0mm Aluminium Casement Windows
Color :
black,etc
Hardware :
handle,lock,fastener,windproof,hinge,etc
Feature :
air permeability,Security,thermal insulation,easy to clean,etc
Type :
Interior Types Casement Windows
Description

Glass Aluminum Window With Aluminum Alloy Frame Tempered Laminated Double Glazed Windows

Features of Aluminum Casement Windows:

A style of windows in folk houses. The opening and closing of window sash moves along a certain horizontal direction, so it is called "casement window".
The casement window is divided into push-pull type and upper suspension type. The utility model has the advantages of large opening area, good ventilation, good sealing, excellent sound insulation, heat preservation and impermeability. The inner opening is convenient for cleaning windows; The open type does not occupy space when it is opened. The disadvantage is that the window width is small and the field of vision is not wide.
The opening of the external window takes up a space outside the wall, which is easy to be damaged in strong wind; The internal opening of windows takes up part of the indoor space. It is not convenient to use screen windows. It is also inconvenient to use screen windows and curtains when opening windows. If the quality is not up to standard, it may leak rain.

Introduction:

A style of windows in folk houses. The opening and closing of window sash is moving along a certain horizontal direction, so it is called "casement window".
Casement windows are divided into push-pull type and hanging type. Its advantages are large opening area, good ventilation, good sealing, sound insulation, heat preservation and impermeability. The inside opening window is convenient to clean, and the outside opening window does not occupy space. The disadvantage is that the window is small and the field of vision is not wide.
The opening of external windows takes up a space outside the wall, which is easy to be damaged when the wind blows; while the opening of internal windows takes up part of the indoor space, so it is not convenient to use the screen windows, and it is also not convenient to use the screen windows and curtains when opening the windows. If the quality is not up to standard, it may also seep rain.

Performance Parameter National Standard
Wind Load Resistance 4.5<=p3>=5.0 level 8
Air Tightness q1<=0.5 level 8
Water Tightness 250<=△p>=350 level 6
Thermal Insulation 2.5<=k<=3.0 level 5
Sound Insulation 30=<Rw+Ctr<35 level 5

Thermal Insulation Glass Aluminum Window Tempered Laminated Double Glazed

Name/Model: Glass Aluminum Window With Aluminum Alloy Frame Tempered Laminated Double Glazed Windows
Profiles: 6063-T5 high quality aluminium extrusion profiles
Glass Choice: Low-e; relective;Frosted; tinted; clear tempered glazing
Glass Choice: 5mm; 6mm,12mm single tempered glazing
5+12A+5mm; 5+27A+5mm; 6+12A+6mm double glass
5+6A+5+6A+5mm triple glass
5+0.76+5mm;6+2.28+6mm Laminated
other glass type you need
Color: matt black;white;ultra silver;clear anodized;nature clean aluminium
Any color available
Customized (matt black;white;ultra silver;clear anodized;nature clean aluminium)
white or other color
Hardware :
China Top brand: MACO
Frame Surface Finish: Powder coated meet AS 3715; Electrophoresis; flucarbon; Anodizing;
Flyscreen: Stainless steel security mesh; Aluminium security mesh; Fiberglass flys
Guarantee : Years
Security: Crimsafe mesh ; Grille available
Application: Building(office/hotel/apartment)
