Specifications
Brand Name :
Henan Yongsheng
Model Number :
Aluminum Round Plate
Certification :
SGS,ISO,etc
Place of Origin :
Henan Province, China
MOQ :
1 Ton
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
5000 Tons per month
Delivery Time :
7-25 days after order confirmation
Packaging Details :
Standard Sea-worthy Packing
Alloy :
1050, 1060, 1070, 1100, 3003, 3004, 3105, 5052, 5754 etc.
Temper :
O,H12,H14,H16,H18,H24,H32,etc
Diameter :
90mm-1020mm (customer requirements)
Thickness :
0.2-6.0mm
Elongation :
≥14%
Tensile Strength :
≥190MPa
Port :
ShangHai, TianJin, QingDao
Sample :
Free
Description

Product Description1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14

High material purity and excellent thermal conductivity
Our aluminum discs are rolled from high-purity aluminum ingots, with an aluminum content of more than 99.7%, ensuring excellent thermal conductivity from the source. In the production of cookware, it can achieve rapid heat conduction and uniform distribution, reducing the situation of local overheating of food ingredients. Whether it is making a frying pan or an electric rice cooker liner, it can make the food heat more evenly, improving cooking efficiency and taste. ​

High thickness accuracy and strong processing stability
Through the precision rolling process, the thickness tolerance of the aluminum disc can be controlled within ±0.02mm, and the flatness error is ≤0.5mm/m. This feature allows cookware manufacturers to effectively reduce mold loss and reduce product scrap rate in stamping, stretching and other processing links, while ensuring the uniform wall thickness of the finished pot and improving the service life.

The surface treatment is adaptable and meets various needs
The surface of the aluminum disc is specially pre-treated, and the roughness can be controlled between Ra0.8-1.6μm, which can perfectly adapt to various surface treatment processes such as non-stick coating and enamel. The coating adhesion is more than 15% higher than the industry average, and it is not easy to fall off or peel, making the cookware more durable, meeting consumers' demand for safe and durable kitchenware.

High food safety level, environmental protection without hidden dangers
Using food-grade primary aluminum material, the production process strictly follows international food safety standards such as SGS and FDA, and does not contain harmful heavy metals and impurities. The processed cookware can directly contact food, and will not release harmful substances under high temperature use, so that manufacturers do not need to worry about food safety compliance issues in the production process.

Technical Parameters

Product Name Aluminum Circle / Aluminum Disc
Standard GB/T3880, ASTM, B209
Series 1050, 1060, 1070, 1100, 3003, 3004, 3105, 5052, 5754 etc.
Temper O,H12,H14,H16,H18,H24,H32,etc
Process Hot rolled (DC) or Cold rolled (CC)
Thickness(mm) 0.2-6.0mm or customized
Diameter(mm) 90mm -1020mm or customized
Tolerance ±1%
MOQ 1 Ton
Sample We can supply 1-2 pieces of free samples.
Appearance Flat, clean surface without scratches, cutting edge no burrs

Chemical omposition(%)
Grade Si Fe Cu Mn Mg Cr Zn Ti Al
1050 0.25 0.4 0.05 0.05 0.05 - 0.05 0.03 99.5
1060 0.25 0.35 0.05 0.03 0.03 - 0.05 0.03
1070 0.2 0.25 0.04 0.03 0.03 - 0.04 0.03 99.6
1100 Si+Fe:0.95 0.05-0.4 0.05 - - 0.1 - 99.7
3003 0.6 0.7 0.05-0.2 1.0-1.5 - - 0.1 - 99
3004 0.3 0.7 0.25 1.0- 0.8 - 0.25 - remains
3005 0.6 0.7 0.3 1.0-1.5 0.2-0.6 0.1 0.25 0.1 remains
3105 0.6 0.7 0.3 0.3-0.8 0.2-0.8 0.2 0.4 0.1 remains
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 0.1 - remains
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 0.25 0.15 remains
5086 0.4 0.5 0.1 0.2-0.7 3.5-4.5 0.05-0.25 0.25 0.15 remains
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 0.25 0.15 remains
6063 0.2-0.6 0.35 0.1 0.1 0.45-0.9 0.1 0.1 0.1 remains

Product Details

1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14

1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14 1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14
1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14 1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14
1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14
1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14
1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14

Applications

1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14

1060 1100 high quality aluminum round sheet for wash basin lamp kitchenware H14
