5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade
Specifications
Outdoor Service Life :
20-25 Years (Per AAMA 2605)
Elongation :
≥12%
Packaging Details :
Export-grade wooden pallet with waterproof kraft paper and PE film wrap, eye-to-sky or eye-to-wall coil orientation, fumigation-free
Temper :
H32 / H34 / H36
Coil Inner Diameter :
405mm / 508mm
Certification :
ISO 9001, SGS, ASTM B209, EN573-1
Delivery Time :
15-25 working days after order confirmation
Coating Thickness :
25-30μm Top Coat + 5-8μm Primer + 7-10μm Back Coat
Tensile Strength :
170-305 MPa
Gloss Level :
20-80 GU (Custom)
Salt Spray Resistance :
≥4000 Hours (ASTM B117)
Maximum Coil Weight :
3-5 Tons per Coil
Payment Terms :
T/T,L/C at sight
Color Options :
Full RAL Colors, Custom Color Matching
Applicable Standard :
ASTM B209, EN573-1, EN1396, GB/T 17748
Brand Name :
Yongsheng
Alloy :
5052 (Al-Mg 2.5%)
Price :
USD 3,500-4,000 / Ton
Thickness :
0.3mm - 3.0mm
Place of Origin :
Henan, China
MOQ :
5 Tons
Supply Ability :
5,000 Tons per Month
Width :
100mm - 1600mm (Custom Slit Available)
Model Number :
5052-PVDF
Yield Strength :
≥65 MPa
Description

5052 PVDF Coated Aluminum Coil — Superior Corrosion Resistance for Demanding Environments

Our 5052 alloy PVDF fluorocarbon coated aluminum coil is engineered for long-term outdoor performance in coastal, industrial, and high-humidity environments. The 5052 alloy (Al-Mg 2.5%) provides exceptional natural corrosion resistance, while the PVDF 70% Kynar 500 fluoropolymer coating delivers unmatched UV stability and chemical resistance for 20-25 years of service life.


5052 PVDF Coated Aluminum Coil 0.3mm-3.0mm Custom Width Weather Resistant for Roofing Gutter Building Facade

Key Performance Advantages
