0.3~10 Mm Thickness Color Coated Aluminum Coil Weather Resistant
0.3~10 Mm Thickness Color Coated Aluminum Coil Weather Resistant
0.3~10 Mm Thickness Color Coated Aluminum Coil Weather Resistant
0.3~10 Mm Thickness Color Coated Aluminum Coil Weather Resistant
0.3~10 Mm Thickness Color Coated Aluminum Coil Weather Resistant
0.3~10 Mm Thickness Color Coated Aluminum Coil Weather Resistant
Specifications
Brand Name :
WILLSTRONG
Model Number :
CCAC AS-06
Certification :
ISO9001, ISO14001, OHSAS18001, INTERTEK, SGS, TUV, PSB, etc
Place of Origin :
CHINA
MOQ :
20Tons
Price :
US $2,300 to 4,800/ Ton
Payment Terms :
T/T, L/C
Supply Ability :
40Tons/Day
Delivery Time :
10-20 Work days
Packaging Details :
Carton and Woodden Pallet
Product name :
Aluminum Coil
Panel Thickness :
0.3~10 mm
Standard size :
1220*2440mm
Aluminum Alloy :
AA1100/AA3003/AA5005/AA5052
Core Layer :
PE/PVDF/FEVE
Application :
For Roofing, manufacturer of ACP, AHP, etc
Material :
Aluminum
Packing :
In cartons and pallets
Description

Basic Information for Color Coated Aluminium Coil

Panel Thickness3~10 mm
Standard size1220*2440mm
Aluminum AlloyAA1100, AA3003
Core LayerPE, Aluminum honeycomb, fr, corrugated aluminum etc..
Width1220mm, 1250mm, 1500mm, 1575mm
Length2440mm, 3200mm, 4000mm, 5600mm
Weightsubject to panel thickness
Surface on front sidePolyvinylidene Fluoride (PVDF), FEVE, PET
Color rangesrefer to WILLSTRONG color chart, or alternative RAL/PANTONE/DULUX color series
Glossinessupon requirements
Back side finishes

protective coating


WILLSTRONG color-coated aluminium coil combines all advantages of modern coil-coating technology in our full-automatic production line. we can created pattern like Wood, stone, graphic as you want. The aluminium substrate gets degreased, chemically pre-treated and coated in a single production step which resulting in a high-quality uniform coating reproducible at any time and a material which has been developed for easy processing for a variety of application.
WHAT COATING MATERIAL CAN BE?
coating material can be: Ployester, PVDF, FEVE, Epoxy, Polyamide, Polyurethan, etc.
WHAT IS THE STRONGPOINT OF WILLSTRONG COLOR COATED ALUMINUM COIL?
Our color Coated Aluminum Coil Characteristics:
- High temperature resistant
- Weathering resistant
- Scrubbing resistant
- Sound insulation
- Acid or alkali proof
- Fireproof
- Light weight material is easy to construct and install
- Bright colors
- Easy molding process,not rusting etc.
WHAT IS THE APPLICATION OF WILLSTRONG COLOR COATED ALUMINUM COIL?
Application:
1. Widely used in insulation board
2. Aluminum curtain wall
3. Aluminum-magnesium-manganese roofing system
4. Aluminum ceiling
5. Acp and many other areas

Product Application

Alucosuper prepainting aluminum coil are made from AA3004 mill finish after degreasing, cleansing and passivated layer processing, and currently most advanced and durable coating materials manufactured by KANAR500 and HYLAR5000 seriess of polyvinylidene fluoride (PVDF) resin. The products are finally molded through other secondary operations including cutting, pressing, punching and bending, which can be applied in overall roofs and building coil for wall decoration with a long span and a large area, be used for decorative coil of interior roofs through being cut into small coil, bending and stamping die processing, and be used for energy-saving exterior wall decoration coil bonding with foaming polyurethane or honeycomb aluminum.

SPECIFICATIONS

Thickness:

0.21-1.5mm normally, could be custom-made

Width:

for coil: 600mm ~ 1800mm, could be custom-made
for sheet: 20mm ~ 1650mm, could be custom-made

Film thickness:

single-coated 4-20 micron double coated 25-28 micron 3 coated 35-38 micron

Coating material:

PVDF, PE, EXPOXY, PU

Colour choose

customer colours are also avliliable

RAL colours can ben availiable

Directly choose colours from alucosuper colour chart



*** Custom specifications are negotiable ***
