Brazing Cladding Aluminum Strip Coil For Charge Air Cooler
Brazing Cladding Aluminum Strip Coil For Charge Air Cooler
Brazing Cladding Aluminum Strip Coil For Charge Air Cooler
Brazing Cladding Aluminum Strip Coil For Charge Air Cooler
Brazing Cladding Aluminum Strip Coil For Charge Air Cooler
Brazing Cladding Aluminum Strip Coil For Charge Air Cooler
Specifications
Brand Name :
Trumony
Model Number :
TR-CY-T098
Certification :
ISO9000, ISO14000, IATF16949
Place of Origin :
China
MOQ :
3 metric tons
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100,000 mt per year
Delivery Time :
35 working days after received your deposit
Packaging Details :
Standard export packaging
Item :
Aluminum strip in coil
Thickness :
0.3mm
Alloy :
1050
Temper :
H24
Surface treatment :
Mill Finish
Width :
35mm
Length :
Customized
ID :
Customized
OD :
Customized
Package :
Eye to sky
Description

Brazing Cladding Aluminum Strip In Coil For Charge Air Cooler

1050 H24 Aluminum Strip In Coil For Auto Condenser

Description

Aluminum strip is an aluminum alloy with an aluminum content of 99.5% or more. aluminum strip is made by slitting aluminum coils. Aluminum strip refers to strip shape product which manufactured with aluminum as the main raw material, and mix other alloy elements.
Specification
Item Aluminum strip in coil
Size Customized as your request
Alloy 4343/3003/4343,4345/3003/4345,3003
Temper H12,H24,O
Application Various kinds of specification for fin

Core Material

Alloy Si Fe Cu Mn Mg Zn Zr Ti code
3003 0.6 0.7 0.05-0.20 1.0-1.5 － 0.1 0.05 0.03 1
3003+1%Zn 0.6 0.7 0.05-0.20 1.0-1.5 － 0.5-1.50 0.05 0.05 2
3003+1.5%Zn 0.6 0.7 0.05-0.20 1.0-1.5 － 1.0-2.0 0.05 0.05 3
3003+1.5%Zn+Zr 0.5-1.0 0.7 0.05-0.20 1.0-1.6 － 1.0-2.0 0.05-0.2 - 4
3003+0.5%Cu 0.6 0.7 0.30-0.70 1.0-1.5 － 0.10 0.05 0.1 5
3005 0.6 0.7 0.20-0.40 1.0-1.5 0.20-0.60 0.25 － 0.01 6

Cladding Material

Alloy Si Fe Cu Mn Mg Zn Zr Ti code
4343 6.8-8.2 0.8 0.25 0.1 － 0.2 － 0.05 1
4343+1%Zn 6.8-8.2 0.8 0.25 0.1 － 0.5-1.5 － 0.05 2
4045 9.0-11.0 0.8 0.3 0.05 － 0.2 － 0.2 3
4045+1%Zn 9.0-11.0 0.8 0.3 0.05 － 0.5-1.5 － 0.2 4
4004 9.0-10.5 0.8 0.25 0.1 1.0-2.0 0.2 － 0.2 5
7072 0.7 0.1 0.1 0.1 0.8-1.3 － － 6
5005 0.3 0.7 0.2 0.2 0.5-1.1 0.5-1.0 － 0.03 7

Brazing Cladding Aluminum Strip Coil For Charge Air CoolerBrazing Cladding Aluminum Strip Coil For Charge Air Cooler

Brazing Cladding Aluminum Strip Coil For Charge Air CoolerBrazing Cladding Aluminum Strip Coil For Charge Air Cooler
