H22 / H24 Aluminum Heat Transfer Foil For Home Air Conditioner Thickness 0.2 mm
H22 / H24 Aluminum Heat Transfer Foil For Home Air Conditioner Thickness 0.2 mm
H22 / H24 Aluminum Heat Transfer Foil For Home Air Conditioner Thickness 0.2 mm
H22 / H24 Aluminum Heat Transfer Foil For Home Air Conditioner Thickness 0.2 mm
Specifications
Brand Name :
Trumony
Model Number :
TR-1100
Certification :
TS16949-2008
Place of Origin :
China
MOQ :
5 Tons
Price :
Negociable
Payment Terms :
L/C, T/T
Supply Ability :
800,000 Per Year
Delivery Time :
30 Working days
Packaging Details :
Strong Wooden Pallets
Alloy :
1100
Feature :
Unclad
Thickness :
0.08mm - 0.2 mm
Cladding Rate :
8%
Shape :
Roll
Description

Alloy 1100 , Thickness 0.2 mm Aluminum Heat Transfer Foil Manufacture For Condenser

Quick Details :

1 . Alloy :1100 ,1200 , 3102 , 8011

2 . Temper : O , H22 , H24 , H26

3 . Thickness : 0.08 - 0.2 mm

4 . Width : 60 - 1440 mm

5 . Inside Diameter : 75 , 150 , 200 , 300 , 400

6 . Outside Diameter : 400 - 1400 mm

H22 / H24 Aluminum Heat Transfer Foil For Home Air Conditioner Thickness 0.2 mm

Chemical Composition ( For Reference Only )

NO

 Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Others Al

1

 1100 0.33 0.27 0.05-0.20 0.05 - - - - - 0.15 99.0

Mechanical Performance ( For Reference Only )

Temper

Tensile Strength

Rm(MPa)

 Yield Strength Rp0.2(Mpa)

Erichsen

(mm)

O
80- 110
20
6.0

H22
100 - 135
16
5.5

H24
 115 -145 12 5.0

H26
125 - 160
 8 4.0

H18
 160 1 -

Our Advantages :

1 . we have extensive experience in providing different presentations and uses aluminum exporting to Mexico, Germany, France, Italy, Korea, Turkey, Iran and India .It has been proven that we have reliable quality and competitive price, customers in these different countries.

2 . We start our productions from aluminum ingot,so we can control the quality as well;

3 . High performance cost rate;
