Extra Wide Aluminium Alloy Sheet 5182 H111 Aluminum Alloy Plate For Tanker
Extra Wide Aluminium Alloy Sheet 5182 H111 Aluminum Alloy Plate For Tanker
Extra Wide Aluminium Alloy Sheet 5182 H111 Aluminum Alloy Plate For Tanker
Extra Wide Aluminium Alloy Sheet 5182 H111 Aluminum Alloy Plate For Tanker
Specifications
Brand Name :
Trumony
Model Number :
5182
Place of Origin :
China
MOQ :
5 tons
Delivery Time :
30days
Packaging Details :
wooden pallet
Synonym :
Aluminum Alloy Plate
Alloy :
5182
Temper :
H111
Thickness :
0.15-600mm
Width :
20-2650mm
Length :
500-16000mm
Description

Extra Wide Aluminum Alloy Sheet / 5182 H111 Aluminum Alloy Plate For Tanker

Product name:5182 H111 Aluminum Alloy Plate

Description of the product:

5182 H111 Aluminum Alloy Plate is one of our best selling products,5182 is the al-mg-si alloy, which has a wide range of usage,because 5182 alloy has good corrosion resistance, excellent weldability, good cold processing, and has a moderate strength, therefore,5182 alloy is widely used in the automotive lightweight aluminum applications.

Chemical composition:

ALLOY NO. Si Fe Cu Mn Mg Cr Zn Ti OTHER AL
1050 0.25 0.4 0.05 0.05 0.05 0.05 0.03 0.03 ≥99.5
1060 0.25 0.35 0,05 0.03 0.03 0.05 0.03 0.03 ≥99.6
1070 0.2 0.25 0.04 0.03 0.03 0.04 0.03 0.02 ≥99.7
1100 0.95(Si+Fe) 0.05-0.20 0.05 0.1 0.05 ≥99
3003 0.6 0.7 0.05-0.2 1.0-1.5 0.1 0.05 Remainder
3004 0.3 0.7 0.25 1.0-1.5 0.8-1.3 0.25 0.05 Remainder
3005 0.6 0.7 0.3 1.0-1.5 0.2-0.6 0.1 0.25 0.1 0.05 Remainder
3104 0.6 0.8 0.05-0.25 0.8-1.4 0.8-1.3 0.25 0.1 0.05 Remainder
4047 11.0-13.0 0.8 0.3 0.15 0.1 0.2 Remainder
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 0.1 Remainder
5252 0.08 0.1 0.1 0.1 2.2-2.8 0.05 Remainder
5754 0.4 0.4 0.1 0.5 2.6-3.6 0.3 0.2 0.15 Remainder
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 0.25 0.15 Remainder
5182 0.2 0.35 0.15 0.2-0.5 4.0-5.0 0.1 0.25 0.1
6061 0.4-0,8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 0.25 0.15 Remainder
6063 0.2-0.6 0.35 0.1 0.1 0.45-0.9 0.1 0.1 0.1 Remainder
6082 0.7-1.3 0.5 0.1 0.4-1.0 0.6-1.2 0.25 0.2 0.15 Remainder
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 5.1-6.1 0.2 Remainder

Technical parameter

Typical alloy: 5182
Temper:

H111,H112,H114,H116,H321

O,H12,H14
Thickness(mm): 0.15-600mm
Width(mm): 20-2650mm
Length(mm): 500-16000mm
Application: The outer plate, deck, refrigeration device, tanker, oxygen Generator tower body of the ship's side ship Bottom

Application in the market:

5182 Aluminum Alloy Plate is mainly used for low-load parts that require high plasticity and good weldability, working in liquid or gaseous media, such as fuel tanks, gasoline or lubricant catheters, various liquid containers and other small load parts made with deep pull: wire is used to make rivets. Thin plate can be used to process canister cover, car body plate, control plate, reinforcement parts, bracket and other parts.
