Customized Aluminum Foil For Refrigerator Production 0.06 - 3.0 mm Thickness
Customized Aluminum Foil For Refrigerator Production 0.06 - 3.0 mm Thickness
Customized Aluminum Foil For Refrigerator Production 0.06 - 3.0 mm Thickness
Customized Aluminum Foil For Refrigerator Production 0.06 - 3.0 mm Thickness
Specifications
Brand Name :
TRUMONY
Model Number :
TR-HEX001,TR-HEX002,TR-HEX003
Certification :
ISO9001-2008
Place of Origin :
China
MOQ :
5 metric tons
Price :
negotiation
Payment Terms :
L/C, T/T
Supply Ability :
50,000 mt per year
Delivery Time :
30 working days after received your down payment
Packaging Details :
Standard export packaging
Material :
Aluminum foil or aluminum sheet
Alloy :
8011，3003，3A21，5052，1060, 1145 and etc.,
Temper :
HO, H22,H14,H24 and etc.,
Width :
12 - 1250mm (max)
I. D. :
150mm, 200mm, 300mm, 400mm, 500mm
Description

Common information

Brand Name: Trumony
Model Number: TR-HEX001,TR-HEX002,TR-HEX003
Certification: ISO9001-2008
Place of Origin: China

Specification of aluminium strip:
1) Alloy: 8011,3003,3A21,5052,1060, 1145 and etc.,
2) Temper: HO, H22,H14,H24 and etc.,
3) Thickness: 0.06-3.0mm

4) Width: 12 - 1250mm (max)
5) I. D.: 150mm, 200mm, 300mm, 400mm, 500mm
6) Normal O. D.: 900-1450mmm
7) coating material: hydrophilic coating;epoxy coating;
8) coating color:blue,gold,green and etc,.
9) Other sizes and specifications are available according to customer's request

ommercial terms

Minimum Order Quantity: 5 metric tons
Price: negotiation
Payment Terms: T/T or LC
Supply Ability: 50,000 mt per year
Delivery Time: 30 working days after received your down payment
Packaging Details: Standard export packaging

Description of our production

Our chemical composition:

Alloy

 Si Fe Cu Mn Mg Zn Cr Ti code
8011 0.5-0.9 0.6-1.0 0.1 0.2 0.05 0.1 0.05 0.08 1
3003 0.6 0.7 0.05-0.2 1.0-1.5 － 0.1 － － 2
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.1 0.15-0.35 － 3
1060 0.25 0.35 0.05 0.03 0.03 0.05 － － 4
1145 Si+Fe:0.55 0.05 0.05 0.05 － － 0.03 5
3A21 0.6 0.7 0.2 1.0-1.6 0.05 0.1 － 0.15 6

Our mechanical property:

Alloy Code temper

Tensile Strength

Rm(MPa)

 Yield Strength Rp0.2(Mpa)

Extend Ratio

A50(%)
8011 O 60-100 ≥45 ≥20
8011 H22 70-110 ≥55 ≥18
3003 H24 140-185 ≥125 ≥3.0
5052 H32 185-225 ≥160 ≥1.0
1060 O 60-95 ≥35 ≥15
1145 H24 95-135 ≥55 ≥4
3A21 H14 140-185 ≥125 ≥3

Produce capability

Width(mm) Thickness(mm) Length(mm) Inside Diameters(mm)
Sheet 200-1300 0.5-5.0 200-2500 -
Strip 12-1300 0.2-3.0 - 150,200,300,400,500
Foil 12-1300 0.05-0.2 - 150,200,300,400,500
