Bare All Aluminum Alloy Conductor AAAC Electric Electrical Cable 25mm2 50mm2 70mm2 95mm2 120mm2 150mm2 240mm2 Power Cable

AAAC is not a "universal" wire, but a "talented student" who performs exceptionally well driven by specific needs. Its core value proposition is to provide a technically mature, reliable, and potentially more cost-effective solution for situations that require excellent corrosion resistance and weight reduction. Its main challenge lies in its thermal expansion characteristics, which require designers to perform meticulous sag tension calculations and cannot be simply regarded as a "direct upgrade" of ACSR.

Service Performance

(1).The permissible long-time operating temperature for aerial conductor is 70oC.

(2).Under the circumstance that rare climate is occuring and ice coverage rate low in heavy ice area,the biggest stress of cable at the lowest point of the sag should not exceed 60% of the short-time destructive power.

(3).When connecting conductors,the conductor beside the connecting tube cant be prominent.Otherwise,the force on the operating conductors will be unbalanced.After connectors are install,the connecting tube should be painted by moisture-proof varnish in order to protect it from corrosion.

(4).Under installaion,the arc downing stress of all the conduct ors should be the same.With in the permissible distance of crossing buildings or dropping to the ground,the stress can be 10-15% higher than regular stress.

Material Standard Of All Aluminum Alloy Conductor

(1).The hard aluminum conductor used for AAC and ACSR conforms to the standard GB/T 17048-1997(equivalent to IEC 60889:1987).

(2).The zinc coated steel wire used for ACSR conforms to IEC 60888:1987.

(3).Production can be arranged according to customers requirements for material standard,etc.

Construction of All Aluminum Conductor and Aluminum Conductor Steel Reinforced

CONSTRUCTION PARAMETERS of 2/0 AWG All aluminium alloy conductor

(*) Note: The values of current rating mentioned in above Table are based on wind velocity of 0.6 metre/second, solar heat radiation of 1200 watt/metre2, ambient temperature of 50° C & conductor temperature of 80°C.

Applications:

• Coastal and highly corrosive areas: have become the preferred or standard configuration for new transmission lines in these areas.
• Urban power grid and distribution lines: Due to their light weight, compact structure, aesthetic appearance (without steel core corrosion pollution), and minimal impact on electrolytic corrosion of surrounding metal facilities, they are increasingly used in overhead lines that are difficult to access in cities.
• Forest fire zone: The temperature of the arc bead generated by aluminum alloy wires during short circuit is relatively low, and it is not easy to ignite vegetation, which has certain fire safety advantages.

FAQ:

Q: Are you trading company or manufacturer ?
A: We have our own factory and trading company, our factory have more than 10 years production experience.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 15-20 days if the goods are not in stock, and it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.L/C is also available.

Q:Have you ever supplied cables to our country ?

A: Cables have been supplied to many countries across the world such as USA, Australia, Switzerland, Singapore, Sri Lanka, the Philippines, Mongolia, UAE, Yemen, Iran, Iraq, Nigeria, Egypt, Lesotho, Cameroon, etc.
