Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Overhead Transmission Bare BS215 ACSR Moose Conductor
Specifications
Brand Name :
Sanwu
Model Number :
ACSR Moose
Certification :
ISO CCC
Place of Origin :
Henan
MOQ :
1000M
Price :
USD1.124 per meter
Payment Terms :
L/C, T/T
Supply Ability :
200 tons per day
Delivery Time :
1-15days
Packaging Details :
Wooden Drum
Material :
Aluminium Conductor Steel Reinforced
Colour :
Natural
Packing :
Wooden Drum
Application :
Overhead Transmission
Standard :
ASTM
Brand :
Luoyang Sanwu
Conductor material :
Aluminum, Steel, Copper, acsr steel core wire, Aluminium & Steel Reinforced
Description

Bare Conductor Widely Used In Power Transmission Lines AAC AAAC ACSR bare Conductor

Material Standard:

ASTM-B232 Standard specification for Concentric-Lay-Stranded Aluminum 1350 Conductors

BS215-2 aluminum conductors steel-reinforced —For overhead power transmission

DIN48204 Steel reinforced aluminum stranded conductors

IEC209 Aluminum stranded conductor steel reinforced

We could produce most of the standards cables, such as ASTM, BS, CSA, DIN, GB and IEC standards, etc.

ACSR Conductor
Code Size (AWG/MCM) Number of Strands(mm) Weight(kg/km) Rated Strength(kg)
Rose 4 7*1.96 58.3 399
Iris 2 7*2.47 92.7 611
Pansy 1 7*2.78 117 740
Poppy 1/0 7*3.12 147.5 897
Aster 2/0 7*3.5 186 1375

Overhead Transmission Bare BS215 ACSR Moose Conductor

Applications
Conductor(AAC and ACSR) have been widely used in power transmission lines with various voltage levels,because they have such good characteristics as simple structure,convenient installation and maintenance,low cost large transmission capacity.And they are also suitable for laying across rivers valleys and the places where special geographical features exist.

Service Performance:
(1). The permissible long-time operating temperature for aerial conductor is 70℃.
(2). Under the circumstance that rare climate is occurring and ice coverage rate low in heavy ice area, the biggest stress of cable at the lowest point of the sag should not exceed 60% of the short-time destructive power.
(3). When connecting conductors, the conductor beside the connecting tube cant be prominent. Otherwise, the force on the operating conductors will be unbalanced. After connectors are install, the connecting tube should be painted by moisture-proof varnish in order to protect it from corrosion.
(4). Under installation, the arc downing stress of all the conductors should be the same. With in the permissible distance of crossing buildings or dropping to the ground, the stress can be 10-15% higher than regular stress.

Overhead Transmission Bare BS215 ACSR Moose Conductor

Quality First ! Customer First ! Service First !

Our products have been repeatedly tested by National Ministry of Electrical Material Test Center, National Electric Wire and Cable Supervision & Inspection Center and Wire and Cable Products Supervision & Inspection Center of Henan province to beQualified Products. We have got China electical products safety certification and in accordance with the IEC standard.
