5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate
Specifications
Brand Name :
RUIYI
Model Number :
5083
Certification :
ISO9001, BV, DNV
Place of Origin :
China
MOQ :
5 Ton
Price :
US$2100- US$3800 Per Ton
Supply Ability :
1000 Ton per month
Delivery Time :
35 days
Packaging Details :
wooden pallets
Product name :
Aluminum Marine plate sheet
Alloy Name :
5083
Temper :
H111, H116, H321
Thickness :
2.0-300mm
Width :
30mm- 2300mm
Length :
300-10000mm
Standard :
AISI, ASTM, BS, DIN, GB, JIS
Description

5083 h116 marine aluminum sheet plate DNV BV SGS 3x2000x6000mm

5052 aluminum sheet is remarkably resistant to seawater corrosion. Its medium to high strength alloy make-up allow for good cold formability and exceptional weldability. Magnesium is the major alloying element for 5052. In the marine industry, it is the primary material for boat hulls and cargo tanks.

5083 aluminum plate

Of all non-heat treatable alloys, this has the highest strength. 5083 is resistant to stress, cracking and exfoliation attack under in marine corrosive conditions. It has a low density and excellent thermal conductivity. It is used across many industries, but primarily shipbuilding.

5086 aluminum sheet shows great results when welded, retaining most of its strength. This factor, along with its corrosion resistance in seawater make it a very popular material choice for the marine industry. 5086 is used extensively for hulls and vessel gangways.

5456 aluminum plate is used as a standard application in welded deck house construction of destroyers. It is a preferred material because of the 40-45% weight reduction with no loss of stability. It can be hot worked and has good strength.

6061 aluminum sheet has good weldability and valuable mechanical properties. It is used most often because of these qualities and its strength and workability. It is used most often in deck-house structures, small boats, and bulk-heads.

5083 H116 Marine Aluminum Sheet 3x2000x6000mm Size Aluminum Sheet Plate

Chemical Analysis of aluminum alloy Plate
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Al
1050 0.25 0.4 0.05 0.05 0.05 - - 0.05 0.03 Remains
1060 0.25 0.35 0.05 0.03 - - - - - Remains
1070 0.2 0.25 0.04 0.03 0.03 - - - - Remains
1100 0.95 0.95 0.05-0.2 0.05 - - 0.1 - - Remains
1200 1 1 0.05 0.05 - - - 0.1 0.05 Remains
3003 0.6 0.7 0.05-0.2 1.0-1.5 - - - 0.1 - Remains
5005 0.3 0.7 0.2 0.2 0.5-1.1 0.1 - 0.25 - Remains
5042 0.2 0.35 0.15 0.2--.5 3.0-4.0 0.1 - 0.25 0.1 Remains
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 - 0.1 - Remains
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 - 0.25 - Remains
5754 0.4 0.4 0.1 0.5 2.6-3.6 0.3 - 0.2 - Remains
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 - 0.25 - Remains
6063 0.2-0.6 0.35 0.1 0.1 0.45 0.1 - 0.1 - Remains
6082 0.7-1.3 0.5 0.1 0.4-1.0 0.6-1.2 0.25 - 0.2 - Remains
7050 0.12 0.15 2.0-2.6 0.1 1.9-2.6 0.04 - 5.7-6.7 0.06 Remains
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 - 5.1-6.1 0.2 Remains
