Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat
Specifications
Brand Name :
RUIYI Aluminum
Model Number :
5052
Certification :
ISO9001, ASTM B209, DNV
Place of Origin :
China
MOQ :
5 Ton
Price :
US$2100-US$3800 Per ton
Supply Ability :
500 Ton per month
Delivery Time :
30 working days
Packaging Details :
pallets
Material :
5052 aluminum plate
Surface :
Mill finish,Bright
Alloy grade :
5052
Features :
PE,PVC coating
Application :
Marine plate, aircraft, containers
Width :
20mm-2500mm
Thickness :
0.2mm -300mm
Temper :
H32
Description

Commercial 5052 marine grade aluminium alloy sheet plate for boat

Aluminium alloy plate 5052 in H32 temper has very good corrosion resistance to seawater and marine and industrial atmosphere. It also has very good weldability and good cold formability. It is a medium to high strength alloy with a strength slightly higher than 5251 and a medium to high fatigue strength.


Alloy aluminium plate 5052-H32 has a range of useful properties:
Decorative Finish | Hard Wearing | Non-Slip | Corrosion Resistant | Low Maintenance | Anti-Static | Light-weight
Amongst the applications for Aluminium Alloy 5052 plate are:
Treadplate | Boilermaking | Containers | Nameplates| Road Signs | Architectural Paneling | Welded Tubes | Chemical Industry | Irrigation | Desalination units | Pressure Vessels | Rivets

Features of 5052 aluminum alloy plate include higher fatigue strength than most aluminum alloys, excellent resistance to salt water atmosphere, excellent weldability and workability, and excellent finishing characteristics

Aluminium alloy 5052 contains nominally 2.5% magnesium & 0.25% chromium. It has good workability, medium static strength, high fatigue strength, good weldability, and very good corrosion resistance, especially in marine atmospheres. It also has the low density and excellent thermal conductivity common to all aluminium alloys. It is commonly used in sheet, plate and tube form.

Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat

What We can supply
Alloy: 1050 1060 1100 3003, 3105, 5052, 5005, 5754 5083 5182, 6061 6063 6082, 7075, 8011…
Temper: HO, H111,H12, H14, H24,H 32, H112, T4, T6, T5,T651
Surface finish: Mill / Emboss / Diamond / 2 bar / 3 bars / Bright / Mirror
Thickness: 0.2mm to 300mm
Width: 30mm to 2300mm
Length:1000mm to 10000mm.


Commercial 5052 Aluminum Sheet , Marine Grade Aluminum Plate For Boat

Chemical Analysis of aluminum alloy Plate
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Al
1050 0.25 0.4 0.05 0.05 0.05 - - 0.05 0.03 Remains
1060 0.25 0.35 0.05 0.03 - - - - - Remains
1070 0.2 0.25 0.04 0.03 0.03 - - - - Remains
1100 0.95 0.95 0.05-0.2 0.05 - - 0.1 - - Remains
1200 1 1 0.05 0.05 - - - 0.1 0.05 Remains
3003 0.6 0.7 0.05-0.2 1.0-1.5 - - - 0.1 - Remains
5005 0.3 0.7 0.2 0.2 0.5-1.1 0.1 - 0.25 - Remains
5042 0.2 0.35 0.15 0.2--.5 3.0-4.0 0.1 - 0.25 0.1 Remains
5052 0.25 0.4 0.1 0.1 2.2-2.8 0.15-0.35 - 0.1 - Remains
5083 0.4 0.4 0.1 0.4-1.0 4.0-4.9 0.05-0.25 - 0.25 - Remains
5754 0.4 0.4 0.1 0.5 2.6-3.6 0.3 - 0.2 - Remains
6061 0.4-0.8 0.7 0.15-0.4 0.15 0.8-1.2 0.04-0.35 - 0.25 - Remains
6063 0.2-0.6 0.35 0.1 0.1 0.45 0.1 - 0.1 - Remains
6082 0.7-1.3 0.5 0.1 0.4-1.0 0.6-1.2 0.25 - 0.2 - Remains
7050 0.12 0.15 2.0-2.6 0.1 1.9-2.6 0.04 - 5.7-6.7 0.06 Remains
7075 0.4 0.5 1.2-2.0 0.3 2.1-2.9 0.18-0.28 - 5.1-6.1 0.2 Remains
