Ultra Narrow Frame Edge Interior Aluminium Pivot Doors 8mm Single Glass
Ultra Narrow Frame Edge Interior Aluminium Pivot Doors 8mm Single Glass
Ultra Narrow Frame Edge Interior Aluminium Pivot Doors 8mm Single Glass
Ultra Narrow Frame Edge Interior Aluminium Pivot Doors 8mm Single Glass
Specifications
Brand Name :
WEINAS
Model Number :
PSCD
Certification :
AS2047
Place of Origin :
Foshan, China
MOQ :
2 Square Meters
Price :
USD55-85 Per Square Meter
Payment Terms :
T/T
Supply Ability :
2000 Square Meters Per Month
Delivery Time :
25-35 Days
Packaging Details :
Foam, Poly Bag Wooden Case
Name :
Interior Aluminium Pivot Door
Material :
Aluminium 6063-T5, Glass
Profile Thickness :
3mm
Panel Thickness :
37mm
Panel Visible Width :
10mm
Glass :
8mm Single Glass
Minimum Wall Occupied Thickness :
55mm(Single Edge Cover), 70mm(Double Edge Cover)
Color :
Black, Grey, White, Brown, Wood Grain
Open Mode :
Swing
Advantages :
High Grade, Brief Design
Description

Single Glass Ultra Narrow Frame Edge Aluminium Interior Pivot Door

Product Description:

Aluminium interior pivot door is a kind of swing door which panel is operated by axle instead of hinge. Axle is assemabled at top and bottom of the panel. But swing axis is off center. Mainly used as partition of interior space. It is high strength, light weight, non-deformable, corrosion-resistant, moisture-proof, fire-resistant, easy to clean and maintain, and highly malleable. Varied of surface treatments (powder coating, wood grain, anodizing, etc.). Providing a wide range of colors and textures.

Aluminium interior pivot door has flexible customizations. Size, color, glass style, surface treatment and opening direction all can be customized according to needs. Matching with large areas of glass design to increase indoor light and space transparency.

Specifications

Product Name:

 Single Glass Ultra Narrow Frame Edge Aluminium Interior Pivot Door
Brand: WEINAS
Model: PSCD
Material: Aluminium Alloy 6063-T5, Glass
Profile Thickness: 3mm
Glass: 8mm Single Glass
Panel: Frame Width 10mm, Panel Thickness: 37mm
Wall Occupied: 55mm(Single Edge Cover), 70mm(Double Edge Cover)
Color: Grey, Black, Brown, White, Wood Grain, Anodized
Advantages: High Grade, Brief Design

Features:

  1. Extreme space saving, especially suitable for small apartment, narrow corridor, bathroom, cloakroom, balcony door, storage room and other areas with limited space.
  2. Modern minimalist aesthetics. Aluminium material and narrow frame design, usually paired with large glass, bring a transparent, stylish and advanced visual effect. Very suitable for modern, minimalist, Nordic, industrial and other decoration styles.
  3. Strong durability. Aluminium is strong, moisture proof, corrosion resistant, non deformable and non cracking material has long service life and is especially suitable for humid environments such as bathrooms, kitchen balcony doors.
  4. Easy to clean and maintain. The surface is smooth and stains are not easy to adhere to. Generally, it can be wiped with a damp cloth.

Ultra Narrow Frame Edge Interior Aluminium Pivot Doors 8mm Single Glass

Ultra Narrow Frame Edge Interior Aluminium Pivot Doors 8mm Single Glass

Ultra Narrow Frame Edge Interior Aluminium Pivot Doors 8mm Single Glass
