High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
LJ Ceramic
Certification :
ISO9001:2008/ROHS
MOQ :
2 piece
Price :
Negotiation
Packaging Details :
Use the export carton which is secure against breakage on the MDF pallet.
Delivery Time :
To be negotiated
Payment Terms :
L/C ，T/T
Description

Wear-Resistant High Temperature Alumina Ceramics Textile Ceramic Machinery Accessories

Alumina ceramic textile machinery accessories are made of alumina ceramic materials and are used in various parts of textile machinery. These accessories are widely used in textile machinery due to their high hardness, wear resistance, high temperature resistance and good insulation properties. Common alumina ceramic textile machinery accessories include wire guides, tensioners, guide wheels, wire guide nozzles, etc.

These ceramic accessories play a vital role in textile machinery, especially in high-speed operation and high-temperature environments. The characteristics of alumina ceramic materials ensure that they can maintain stable performance for a long time under extreme conditions, while reducing equipment downtime and maintenance costs.
Our company specializes in customizing ceramic textile machinery accessories!

Ceramic Properties Table
Name 99ceramic 95ceramic Zirconia
Main Ingredients Al2O3>99% Al2O3>95% ZrO2≥94%
Physical properties Density 3.85 3.6 5.9
Water Absorption％ 0 0 0
Sintering temperature°C 1690 1670 1650
Material properties Hardness HV 1700 1600 1400
Flexural strength 4pt >3500 ＞2900 >11000
Compressive strength Kgf/㎡ 30000 25000 25000
Thermal properties Maximum operating temperature°C 1500 1400 1600
Coefficient of thermal expansion 8 7.8 10
10-6/°C
0-1000°C
Electrical Characteristics Thermal shock resistance T(°C) 200 220 350
Thermal conductivity W/m.k 31 22 3
Volume resistivity Ω.cm >10¹² >10¹² >10¹²
Dielectric breakdown strength KT/m 18 16 15
Dielectric constant 1MHZ(E) 9.2-10.5 9.0-10 12.5

High Temperature Alumina Oxide Textile Machinery Precision Ceramic PartsHigh Temperature Alumina Oxide Textile Machinery Precision Ceramic PartsHigh Temperature Alumina Oxide Textile Machinery Precision Ceramic PartsHigh Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts

Purchase process

High Temperature Alumina Oxide Textile Machinery Precision Ceramic Parts

FAQ

Q1: Are you a manufacturer or a trader?
A1: We are a real manufacturer, our factory is specialized in producing refractory materials for more than 20 years. We promise to provide the best price, the best pre-sale and after-sale service.

Q2: How do you control your quality?
A2: For each production process, LJ has a complete QC system for chemical composition and physical properties. And we will test the goods, and the quality certificate will be shipped with the goods. If you have special requirements, we will try our best to accommodate them.

Q3: What is your delivery time?
A3: Depending on the quantity, our delivery time is different. But we promise to ship as soon as possible with guaranteed quality.

Q4: Do you provide free samples?
A4: Of course, we provide free samples.

Q5: Can we visit your company?
A5: Yes, of course, you are welcome to visit LJ company and our products.

Q6: What is the MOQ for trial order?
A6: There is no limit, we can provide the best suggestion and solution according to your situation.

Q7: Why choose us?
A7: We have been making refractory materials for more than 20 years, we have strong technical support and rich experience, we can help customers design different kilns and provide one-stop service.
