$Refractory Alumina Ceramic Balls Heat Resistant Mullite Ceramic Electrical Ceramic$

Specifications

Place of Origin :

Jiangsu, China

Brand Name :

LJ Ceramic

Certification :

ISO9001:2008/ROHS

MOQ :

2 piece

Price :

Negotiation

Packaging Details :

Use the export carton which is secure against breakage on the MDF pallet.

Delivery Time :

To be negotiated

Payment Terms :

L/C ，T/T

Model Number :

Alumina Ceramic Ball

Description

Refractory Heat Resistant Mullite Ceramic Heating Square Plates Electrical Ceramic

Technical Parameter:

Model		Alumina Ceramic Ball
Color		Pure White/lvory
Shape		Ball
Typical Technical Composition		Min. %	Max. %	Usual%
SiO2		******	0.2	0.18
Al2O3		99	99.6	99.3
Fe2O3		******	0.2	0.02
TiO2		******	0.55	0.02
CaO		******	0.1	0.02
MgO		******	0.1	0.05
Na2O		******	0.25	0.01
K2O		******	0.2	0.13
Physical properties
Index		Value	Value
Leachable Iron		≤ 0.01%	******
Apparent Porosity by Weight		≤ 7.0%	******
Moh's Hardness Scale		>8.0	******
Water Absorption		<4.0 wt.%	******
Acid Resistance		>99.8%	******
Thermal Conductivity		0.7-0.8 w/m2.k	******
Thermal Expansion @ 500		0.10%	******
Thermal Shock Stability, 1000 then water cooling		10 times	******
Max. Operating Temperature		1550°C	2822
Specific Density		3400 kg/m3	212 lb/ft3
Bulk Density (Packing Density)		2000 kg/m3	131 lb/ft3
Crush Strength
Size		Crush Strength
Nominal Size		(lbs)	(kg)	(N/pc)
mm	inch	min.	min.	min.
3	1/8"	115	52	510
6	1/4"	230	105	1030
10	3/8"	440	200	1961
13	1/2"	1355	615	6031
16	5/8"	1720	780	7650
19	3/4"	2315	1050	10297
25	1"	3130	1420	13925
38	1-1/2"	4034	1830	17946
50	2"	4960	2250	22065
Typical Application		a)high temperature and steam b)has very excellent thermal properties, with its high density high-temperature resistance 1550. c)it's suitable for applications in olefin processes, such as ethylene dryers

Features:

1) A variety of specifications available.
2) Satisfy various technical request
3) Lower medium spoilage
4) Good insulation performance and high temperature resistance
5) Stiffness texture
6) Used in all electric products and electric heating products
7) OEM, ODM and OBM are welcomed
