How to choose aluminum square tube size based on space?
How to choose aluminum square tube size based on space?
How to choose aluminum square tube size based on space?
How to choose aluminum square tube size based on space?
Specifications
Brand Name :
TianYuan
Model Number :
ODM
Place of Origin :
Guangzhou
MOQ :
100
Price :
8-999
Payment Terms :
30% deposit upon order placement, balance paid before shipment.
Supply Ability :
100000 m² per month
Delivery Time :
3-15 working days
Packaging Details :
Film wrapped with bubble wrap; wooden framing when required.
Size :
Customized Size
Wall Thickness :
1.0mm To 5.0mm
Stain Resistant :
Yes
Moistureproof :
Yes
Advantage :
Environmental Friendly
Length :
Standard 6 Meters / Custom Length Available
Shape :
T-slot / U-channel / L-angle / Custom
Mechanical Strength :
High Strength-to-weight Ratio
Description

Profiled Aluminum Square Tubes: The All-Round Material for Modern Architectural Decoration

Profiled aluminum square tubes are long strip-shaped decorative profiles made from high-purity aluminum alloy through the supergravity extrusion molding process. They boast excellent hardness, straightness, and deformation resistance.

Core Characteristics:

  • Lightweight material: Low density reduces building load-bearing pressure, facilitating transportation and installation.
  • Superior strength: Hardness and straightness far exceed ordinary aluminum square tubes, with stable structure and no easy deformation.
  • Wind and earthquake resistance: Special groove design enables firm connection with customized components, suitable for high-rise buildings and outdoor environments.
  • Fire safety: Class A non-combustible material, high temperature resistant, with no fire hazards.
  • Strong weather resistance: A natural oxide film forms on the surface, resisting acid-base corrosion and rust, with a service life of 15-20 years.

How to choose aluminum square tube size based on space?

II. Detailed Classification and Specifications

1.Classification by Manufacturing Process

Type

Forming Method

Features

Applicable Scenarios
Profiled aluminum square tubes Extrusion molding with special aluminum ventilation materials High hardness, good straightness, stable structure, strong wind resistance Outdoor curtain walls, large public buildings, high-rise buildings
Aluminum plate square tubes Continuous rolling or cold bending forming Lower cost, easy installation, lighter weight Indoor ceilings, commercial spaces, home decoration
U-shaped aluminum square tubes Strip design with three-sided sealing Good ventilation and exhaust, effective pipeline shielding Indoor ceilings, corridors, feature walls

2. Specification Parameters (Unit: mm)

Standard specification range:

  • Bottom width: 20-400 (common: 50, 80, 100, 150)
  • Height: 20-600 (common: 50, 100, 200)
  • Wall thickness: 0.4-3.5 (0.6-1.2 recommended for indoor use, ≥1.5 for outdoor use)

Special specifications: Up to 300×150×3.5mm, meeting the needs of large-scale projects.

3. Classification by Cross-Section Shape

  • Standard square tubes: Square or rectangular cross-section, simple and elegant.
  • U-shaped square tubes: Groove design, ventilated and light-transmitting, suitable for hiding pipelines.
  • V-shaped square tubes: Herringbone cross-section, enhancing spatial three-dimensional sense.
  • Curved square tubes: Straight square tubes can be bent into curves through special processes to create a sense of flow.

Special-shaped square tubes: Customized design to meet personalized needs.

How to choose aluminum square tube size based on space?

III. Surface Treatment Processes and Effects

Profiled aluminum square tubes offer diverse surface treatments to meet different design style requirements:

  1. Powder coating: Rich colors (over 60 standard colors), strong weather resistance, no easy fading.
  2. Fluorocarbon coating: Preferred for outdoor use, UV and acid-base resistant, with a color retention period of over 10 years.
  3. Wood grain transfer printing: Simulates natural wood texture, combining the warmth of wood with the durability of metal.
  4. Stone/marble grain: Enhances spatial luxury, suitable for high-end venues.
  5. Anodizing: Forms a natural oxide film, with high hardness and wear resistance.
  6. Electroplating treatment: Presents a metallic mirror effect, enhancing spatial grandeur.

IV. Comprehensive Analysis of Core Advantages

1. Space Shaping Advantages

  • Visual extension: Linear arrangement stretches the sense of space and enhances the visual effect of floor height.
  • Transparency and lightness: Open structure reduces spatial oppression and distributes light more evenly.
  • Layer creation: Creates spatial rhythm through different spacing, heights, and arrangement methods.
  • Guiding function: Straight-line arrangement guides sight and strengthens spatial orientation.

How to choose aluminum square tube size based on space?

2. Functional Performance Advantages

Advantage

Specific Performance

Application Value
Fire safety Class A non-combustible material, high temperature resistant, no toxic gas release when exposed to fire Crowded places such as hospitals, schools, and shopping malls
Moisture and corrosion resistance Aluminum alloy material + surface treatment, no mildew or rust Bathrooms, kitchens, buildings in coastal areas
Acoustic optimization Combination of punching design and sound-absorbing cotton, with a noise reduction coefficient (NRC) ≥0.7 Open offices, restaurants, gymnasiums
Ventilation and heat dissipation Open structure promotes air circulation and reduces spatial temperature Equipment rooms, subway stations, swimming pools
Pipeline hiding Can cover ceiling pipes and lines to maintain spatial tidiness Commercial complexes, office buildings, underground garages

3. Installation and Maintenance Advantages

  • Simple and efficient: Independent unit design, no special tools required for installation and disassembly.
  • Flexible adjustment: Keel spacing can be adjusted arbitrarily to adapt to different spatial needs.
  • Low maintenance cost: Smooth surface, not easy to accumulate dust, only regular cleaning required.
  • Long service life: 3-4 times that of wood materials, with maintenance cost only 1/5-1/10 of wood materials.
  • Environmental protection and recyclability: Aluminum alloy materials can be 100% recycled and reused, complying with green building concepts.
