Specifications
Brand Name :
TianYuan
Model Number :
TY-010
Certification :
CE,ISO9000...
Place of Origin :
Made in China
MOQ :
1*20"container
Price :
USD15.7/m2
Payment Terms :
L/C, T/T
Supply Ability :
9000M2/days
Delivery Time :
15-20days
Packaging Details :
1pcs/PE packing /box /wood packing
Product Name :
Curved Aluminum Square Tube
Product Thickness :
0.5-3.0mm (Customizable)
Product Color :
All colors customizable
Application scenarios :
Indoor ceilings Outdoor curtain walls
Description
Wood Grain Aluminum Ceiling Battens
Wood grain aluminum ceiling battens combine natural wood aesthetics with aluminum alloy performance, offering exceptional visual appeal, practicality, and environmental benefits for diverse architectural applications.
Wood Grain Aluminum Battens for Ceilings, Decorative Aluminum Square Tubes, Spray-Painted & Baked-Enamel Aluminum Battens, Partition Aluminum Battens, Curved Aluminum Batten Profiles
Aesthetic Value & Style Adaptability
Hyper-Realistic Wood Texture
Advanced heat transfer and 3D wood grain replication processes deliver textures and tactile sensations nearly identical to natural wood, capturing subtle grain details while avoiding wood's inherent flaws like knots and color variations.
Versatile Styling Options
Available in various wood species including walnut, oak, and maple, combined with diverse specifications and shapes to fit styles from minimalist modern to new Chinese, meeting high-end texture requirements for commercial spaces.
Enhanced Spatial Layering
The grid structure provides transparency, breaking up monotonous surfaces while light and shadow interplay through gaps to deepen spatial depth, adding design flair to ceilings and walls.
Wood Grain Aluminum Battens for Ceilings, Decorative Aluminum Square Tubes, Spray-Painted & Baked-Enamel Aluminum Battens, Partition Aluminum Battens, Curved Aluminum Batten Profiles
Common Specifications
  • Width (W): 20-400mm (commonly 30-200mm)
  • Height (H): 20-600mm (commonly 50-200mm)
  • Thickness (δ): 0.4-3.5mm (0.5-1.2mm for ceilings; 1.5-3.0mm for curtain walls)
  • Length (L): 1-6 meters (customizable)
Popular Specification Combinations
30×80×0.6mm, 40×60×0.8mm, 50×100×1.0mm, 30×50×0.8mm
U-shaped battens: U25 (25×50-120mm), U30 (30×50-120mm)
Specification Selection Guide
  • Ceiling height ≤3m: Choose narrow widths (30-50mm) for lightweight visual effect
  • Ceiling height >4m: Opt for wider widths (100-200mm) to enhance spatial layering
  • Ceilings: 50-150mm height, 0.6-1.0mm thickness
  • Curtain walls/partitions: 100-300mm height, 1.0-2.0mm thickness
Wood Grain Aluminum Battens for Ceilings, Decorative Aluminum Square Tubes, Spray-Painted & Baked-Enamel Aluminum Battens, Partition Aluminum Battens, Curved Aluminum Batten Profiles
Surface Treatment Comparison
Treatment Process Features Application Scenarios
Heat Transfer Wood Grain Realistic wood texture, natural touch, long-lasting color Indoor ceilings, furniture, room dividers
Fluorocarbon Coating Exceptional weather resistance (20+ years), UV protection, self-cleaning Exterior walls, high-rise buildings, outdoor projects
Electrostatic Powder Coating Rich color options, moderate cost, strong adhesion Regular indoor use, cost-effective choice
Roll Coating Uniform coating, smooth surface, suitable for large areas Commercial spaces, corridor ceilings
Lamination Strong three-dimensional effect, premium texture, easy to clean High-end commercial projects, custom designs
3D Wood Grain Ultra-realistic 3D texture, nearly indistinguishable from real wood, complex process Museums, high-end exhibition halls
Wood Grain Aluminum Battens for Ceilings, Decorative Aluminum Square Tubes, Spray-Painted & Baked-Enamel Aluminum Battens, Partition Aluminum Battens, Curved Aluminum Batten Profiles
Installation & Maintenance
Installation Methods
  • Snap-On Type: Specialized keels + windproof clips for quick installation and easy removal (ideal for ceilings)
  • Screw Fixation: Used for curtain walls/partitions; connects to keels via profile grooves for strong wind resistance
  • Special Shapes: Curved/wave-shaped battens require custom processing and modular splicing for enhanced visual impact
Maintenance Tips
  • Daily Cleaning: Wipe with a damp cloth - no special cleaners needed
  • Regular Inspection: Check fasteners every 2 years and re-tighten if loose
  • Stain Removal: Use neutral cleaners for stubborn stains; avoid strong acids/alkalis
Wood Grain Aluminum Battens for Ceilings, Decorative Aluminum Square Tubes, Spray-Painted & Baked-Enamel Aluminum Battens, Partition Aluminum Battens, Curved Aluminum Batten Profiles
