PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
Specifications
Brand Name :
TianYuan
Model Number :
TY-010
Certification :
CE,ISO9000...
Place of Origin :
Made in China
MOQ :
1*20"container
Price :
USD15.7/m2
Payment Terms :
L/C, T/T
Supply Ability :
9000M2/days
Delivery Time :
15-20days
Packaging Details :
1pcs/PE packing /box /wood packing
Product Name :
Curved Aluminum Square Tube
Product Thickness :
0.5-3.0mm (Customizable)
Product Color :
All colors customizable
Application scenarios :
Indoor ceilings Outdoor curtain walls
Description
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls
Export-grade double-curved aluminum alloy veneer available with wood grain finish or silver gray coating.
Product Overview
Aluminum veneer offers comprehensive advantages including lightweight strength, durability, versatile design, safety, and environmental friendliness, making it the preferred material for modern commercial storefronts. Suitable for both chain enterprises seeking brand consistency and independent shops aiming for unique identity, aluminum veneer provides complete solutions from design to installation. It enhances storefront aesthetics while reducing long-term maintenance costs, creating sustained value for businesses.
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
Technical Specifications
Parameter Specification Range Recommended Configuration for Storefronts
Panel Thickness 1.5mm, 2.0mm, 2.5mm, 3.0mm ≥2.0mm for outdoor use; ≥3.0mm for large storefronts
Standard Size Width: 1220mm, 1524mm; Length: ≤6000mm 1220×2440mm (4×8ft) - most commonly used
Bending Radius ≥1.5×panel thickness R=5mm for curved storefronts
Reinforcement Ribs Thickness: 2.0-3.0mm; Spacing: 300-500mm Mandatory for storefronts ≥1.5m in height; 400mm spacing
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
Surface Treatment Options
PVDF Coating
Three-coat one-bake process with total thickness ≥70μm; exceptional weather resistance maintains color fastness for 15-20 years outdoors without fading. Resistant to acid rain, salt spray, and UV rays; surface hardness reaches 6H, featuring easy cleaning and self-cleaning properties. Ideal for high-end commercial projects, coastal areas, and long-term outdoor applications.
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
Powder Coating
Electrostatic spraying process with thickness ≥60μm; vibrant colors, strong adhesion, and solvent-free environmental friendliness. Maintains performance for over 10 years indoors and 5-8 years outdoors, offering high cost-effectiveness. Perfect for indoor storefronts, mall shops, and budget-conscious projects.
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
Anodizing
Forms a hard oxide film (thickness: 8-25μm) with strong metallic finish, hardness comparable to stainless steel. Scratch-resistant and acid-alkali resistant, perfect for industrial-style designs and humid environments. No additional coating required; simple maintenance, cost-effective between PVDF and powder coating.
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
Application Scenarios
Mainstream Commercial Applications
  • Brand Chain Stores: Standardized production ensures consistent brand image across national stores; fast installation supports brand expansion. Examples include curved storefronts for beverage shops, custom perforated designs for clothing stores, and minimalist flat panels for convenience stores.
  • High-End Commercial Buildings & Office Towers: Custom shapes enhance commercial space quality; PVDF coating delivers premium, long-lasting texture. Applications include large curved surfaces for shopping mall main entrances and metallic-finish storefronts for office lobbies.
  • Public Building Entrances: Fire-safe, easy to clean and maintain, complying with public building regulations. Suitable for elegant facades for bank branches, prominent signage for hospital entrances, and modern designs for school gates.
Specialized Scenario Solutions
  • Coastal Areas: 5052-H32 alloy + PVDF coating resists salt spray erosion, extending service life by 30%.
  • Northern Frigid Regions: 6061-T6 alloy with excellent toughness, resistant to freezing cracks and snow loads.
  • High-Foot Traffic Areas: Surface-hardened treatment for impact resistance; daily cleaning requires only water.
  • Creative Design Needs: Laser cutting + bending processes to achieve any shape, including 3D brand logo designs.
PVDF-Coated Perforated Aluminum Veneer for Storefront & Exterior Walls - Export-Grade Double-Curved Aluminum Alloy Veneer with Wood Grain Finish/Silver Gray
