Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Specifications
Brand Name :
JERO
Model Number :
JA78
Certification :
IATF 16949 CE ISO IRIS EN 45545
Place of Origin :
CHINA
MOQ :
7 tons
Price :
2800-3200USD/TON
Payment Terms :
T/T,L/C
Supply Ability :
3,000 tons per month
Delivery Time :
20-28 working days
Packaging Details :
standard export packages
Type :
Aluminum alloy plate
Alloy :
EN AW 5754
Application :
Dashboard bracket
Thickness :
4-15 mm
Trade terms :
CIF, CNF, FOB, EXW
Description
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Automotive Body Panel
Product Specifications
Attribute Value
Type Aluminum alloy plate
Alloy EN AW 5754
Application Dashboard bracket
Thickness 4-15 mm
Trade terms CIF, CNF, FOB, EXW
Product Overview
5754 alloy is a non-heat-treatable aluminum-magnesium alloy, widely used for automotive production, particularly for body panel and structural components. It offers an excellent balance of strength, formability, and corrosion resistance.
Our Manufacturing Capabilities
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
  • Streamlined and standardized workflows for efficient production
  • Optimized work environment fostering productivity and team cohesion
  • World-leading technology and equipment for aluminum plate production
  • Specialization in large size and mass production capabilities
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Advanced Production Equipment
Code Name Brand
a Aluminum ingot melting furnace GAUTSCHI (Switzerland)
b 2800mm width single stand cold rolling mill SMS Group (Germany)
c 4 continuous hot rolling mills SMS Group (Germany)
d Heavy crop and dividing shear SMS Group (Germany)
e Coil material annealing furnace SMS Group (Germany)
f All automatic three-dimensional elevated warehouse Dematic (USA)
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
Technical Specifications
For automotive body panel applications, the most common tempers for 5754 aluminum are:
  • H22: 1/4 hard - Offers good formability with moderate strength
  • H24: 1/2 hard - The most typical temper providing optimal balance of strength and formability, ideal for stamping parts like doors, hoods, and fenders
Material Characteristics
  • Material Composition: Al-Mg alloy (2.6-3.6% Mg), non-heat-treatable (strengthened by cold working)
  • Corrosion resistance: Superior to 6xxx series (no intergranular corrosion risk), ideal for humid/salty environments
  • Weldability: Excellent (MIG/TIG welding retains >90% strength)
Mechanical Properties
Temper Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
O 220-260 80-120 ≥15
H32 270-320 150-200 ≥10
Comparative Analysis
Process Stage 5754 (Al-Mg) 6061 (Al-Mg-Si)
Formability Excellent Requires annealing
Weldability Superior (no cracking) Needs PWHT
Surface Treatment Lower cost Moderate cost
Weight Reduction 60%+ vs steel 60%+ vs steel
European Market Preference for 5754
  • Higher Magnesium Content (~3% Mg vs. 5052's 2.2-2.8%) provides better corrosion resistance
  • Compliance with strict EU environmental standards
  • Superior weld integrity with less cracking risk than 5052 in critical joints
Al Mg Alloy EN AW 5754 Aluminium Alloy Plate Sheet Automotive Body Panel
