Aluminium Composite Panel (ACP)
Aluminium Composite Panel (ACP)
Specifications
Model Number :
ACP
Payment Terms :
L/C
Packaging Details :
WOODEN or NORMAL PACKAGE
Place of Origin :
China
Supply Ability :
3000 SQM PER DAY
Brand Name :
KINGWINS/ OEM
MOQ :
800 SQM / PER COLOUR
Delivery Time :
10-15 WORKING DAYS
Description
What is Kingwins Aluminium Composite Panel (ACP)?

Aluminium Composite Panel (ACP) is a sandwich-structured composite material made by bonding two outer layers of aluminum sheet with a middle layer of LDPE (low-density polyethylene) core material (or a mineral-filled fire-retardant core) through continuous extrusion and hot-pressing processes. The surface of the aluminum sheets is coated with fluorocarbon or polyester paint using a roller-coating process. Since its introduction over 50 years ago, aluminum composite panel has been widely favored by property owners, designers, and construction contractors for its lightweight, cost-effective, user-friendly, and durable characteristics.

Panel width: 1000mm, 1220mm, 1250mm, 1500mm, 1575mm, 2000mm or customized widths.
Panel length: 2440mm, 3200mm, 4880mm, 5800mm or cut to size
Panel thickness: 3mm, 4mm, 5mm, 6mm, up to 15mm
Aluminium skin thickness: 0.12mm, 0.15mm, 0.2mm, 0.3mm, 0.4mm, 0.5mm
Alloy: AA1100, AA3003, AA5005
Core: LDPE core (Low density Polyethyelene), FR B1 core, FR A2 core
Coating: PVDF, FEVE, PE, Anodized etc
Color Series of KINGWINS Aluminium Composite Panel (ACP):
Aluminium Composite Panel (ACP)





Features of Aluminium Composite Panel (ACP):
  • Lightweight. Comparing to solid aluminium panels at same thickness, the weight of composite panel is 40% lighter.
  • Smooth surface and consistent color within one batch. Composite panel is made with pre-painted roller coating coils, the coating is smooth and color is consistent, while aluminium solid panel is powder coated with a rough surface and color deviation within one batch might be more obvious.
  • Lots of color to make it easy to design a good looking building facade.
  • Easy to fabricate and install at job site, it can be cut and drill, grooved, bent, no need to pre-fabricated at manufacturer's mill.
  • Fireproof. FR B1 is becoming more and more commonly used, and FR A2 grade is created to meet some building which requires a much higher fire safety demand.
